Prefab Steel Workshop Structure with Skillion Roof PU Panels

Prefabricated steel structure workshop buildings designed for industrial applications featuring a skillion roof design. Ideal for CNC machine processing factories and other industrial facilities.

• Main structure: H section steel Q355 with alkyd painting
• Roof purlin: XZ160*60*20*2.5, galvanized
• Wall purlin: XZ160*60*20*2.5, galvanized
• Intensive bolt: Grade 10.9
• Turn buckle bolt: M20+2, steel Q235
• Anchor bolt: M24, steel Q235

• Cross brace: Φ20 round steel bar Q235
• Angle brace: L50*5 angle steel Q235
• Column bracing: Φ25 round steel bar Q235
• Tie bar: Φ127*3 steel pipe Q235
• Batter brace: Φ32*2.5, Φ12 round steel bar Q235

• Roof panel: PU sandwich panel
• Wall panel: PU sandwich panel
• Edge cover: 0.5mm color plate, angle Alu
• Unpowered ventilator: Diameter Φ600, stainless steel
• Sky lighting band: 1.2mm FRP, double layer
• Sliding door: sandwich panel door

We provide comprehensive design and fabrication services for customized steel structure buildings including warehouses, workshops, storage facilities, hangars, and various industrial structures. Our expertise covers both light and heavy steel structures in portal frame and dome frame configurations.

All structural components, panels, bolts, and accessories are carefully packed in standard ocean transportation packaging and loaded into 40'HQ containers. Our skilled workers handle loading using cranes and forklifts to prevent any damage to the goods.

• Quick construction with prefabricated components
• Cost-effective solution with reduced foundation requirements
• Lightweight yet durable steel structure
• 50-year service life with proper maintenance
• Versatile applications for various industrial needs
