Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan

Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan
Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan
Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan

Large Image :  Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV
Model Number: Ruly0167
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan

Description
Features: Steel Structure Factory Buildings Application: Prefab Steel Buildings Construction
Other Usage: Steel Structure Warehouse, Workshop, Factory Building Working Scope: Design,Fabrication, Installation
Raw Steel Material: Q235B, Q355B Surface Treatment: Painting Or Hot-dip Galvanize
Service Life: 50 Years Wall And Roof: Glass Wool
Highlight:

prefab steel buildings

,

steel structure factory building

Q235B / Q355B Prefab Steel Buildings Construction Steel Structure Factory Buildings
Key Attributes
Application Prefab Steel Buildings Construction
Features Steel Structure Factory Buildings
Other Usage Steel Structure Warehouse, Workshop, Factory Building
Working scope Design, Fabrication, Installation
Raw steel material Q235B, Q355B
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof Glass wool
About Steel Structure Warehouse Buildings

Q235B/Q355B prefabricated steel buildings are designed for industrial applications including factories, warehouses, workshops, and hangars. These structures are ideal for single-story, large-span buildings with simple construction and short project timelines.

Project Specifications
Structure Type Portal frame, single ridge, two spans
Dimensions 100m (Length) × 50m (Width)
Eave Height 12m
Roof Slope 10%
Gable Wall Column Spacing 7.5m
Roof/Wall Material 150mm thick glass wool composite panel
Door/Window Sliding door / Ribbon Skylight
Height Difference 300mm (indoor vs outdoor)
Technical Components
Main Steel Frame System
Main structure H section steel Q355, alkyd painting
Roof/Wall purlin XZ160*60*20*2.5, galvanized
Fasteners Grade 10.9 intensive bolts, M20/M12 galvanized bolts
Bracing System
Cross brace Φ20 round steel bar Q235, painted
Angle brace L50*5 angle steel Q235, painted
Column bracing Φ25 round steel bar Q235, painted
Wall & Roof System
Panels 150mm Glass wool sandwich panel
Ventilation Φ600 stainless steel unpowered ventilator
Drainage 0.5mm color steel gutter with Φ110 PVC pipes
Our Manufacturing Facility

Our 35,000㎡ fabrication facility includes 20,000㎡ of workshop space equipped with advanced production lines for H steel, BOX sections, C/Z purlins, and profiling steel sheets.

Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan 0
Our Services
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Complete design, fabrication, and installation of prefabricated steel buildings
  • Shop drawing development based on architectural plans
  • Engineering consulting services
Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan 1
Packaging & Shipping

All components are packed for ocean transportation in 40'HQ containers. Our skilled workers handle loading using cranes and forklifts to prevent damage during transit.

Q235B Q355B Prefab Steel Structure Factory Building 50 Year Lifespan 2
