Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B

Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B
Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B
Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B

Large Image :  Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0091
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B

Description
Features: Architectural Structural Steel Application: Arch Roof Steel Building
Type: Curved Structural Steel Beam Raw Steel Material: Q235B, Q355B, ASTM A36
Service Life: 50 Years Wall And Roof: Steel Cladding Sheet
Surface Treatment: Painting Working Scope: Design,Fabrication, Installation
Highlight:

steel building structures

,

steel truss structure

Curved Architectural Structural Steel Beam / Arch Roof Building Structure Steel
Product Attributes
Attribute Value
Application Arch Roof Steel Building
Type Curved Structural Steel Beam
Features Architectural Structural Steel
Raw steel material Q235B, Q355B, ASTM A36
Service life 50 Years
Wall and Roof Steel cladding sheet
Surface treatment Painting
Working scope Design, Fabrication, Installation
Product Description

Curved Architectural Structural Steel Beam / Arch Roof Building Structure Steel is designed for warehouse buildings, featuring precision-engineered curved H-shaped steel beams and accurate installation of roofing profiled steel plates.

Key Construction Points
  • Precision production of H-shaped steel curved beams
  • Accurate installation of roofing profiled steel plates
  • Specialized arc shaping of conventional linear H-shaped steel beams
Steel Structure Specifications
Item name Specification Material Parameter Technical Treatment
Column H shaped steel Q235B, Q345B Paint or Hot dip galvanized
Beam H shape steel, arc shaped steel beam Q235B, Q345B Paint or Hot dip galvanized
Bracing Steel rod, Steel pipe, Angle steel Q235B, Q345B
Purling C or Z shape, purling Thickness: 1.8mm~3.0mm Q235B, Q346B Hot dip galvanized
Wall and roof panel EPS, Rock wool, Pu, Glass wool Sandwich panel or Single sheet Steel T=0.426~0.8mm, insulation T=50~150mm Alu-zinc 150g, Fluorocarbon paint
Door Sliding or rolling door Steel or Aluminum sheet, T=1.0~1.5mm Paint or Hot dip galvanized
Window alloy-Glass, Aluminium alloy-shutter T=1.0~2.0mm Alloy
Lighting panel FRP, T=1.5mm or T=1.8mm Coefficient of thermal expansion: 2.2x10-5/cm/cm/℃ Light transmittance 85%
Ventilator Turbine ventilator, and electric type Steel, stainless steel, PC Paint or Hot dip galvanized, 304
Gutter Galvanized or stainless steel plate T=2.0mm Hot dip galvanized, 304
Downpipe PVC pipe, Color steel pipe T=0.5mm Φ110, 160, 200 Paint
Bolt Ordinary, high strength 10.9S, 4.8s Hot dip galvanized
Anchor bolt Steel rod M24, M27 M30 Q235B
Our Steel Structure Production Line

Our fabrication facility spans 35,000㎡ with a 20,000㎡ workshop area, equipped with:

  • Three light/heavy H steel production lines
  • BOX production lines
  • C/Z purlin production lines
  • Various profiling steel sheet machines
  • Advanced plasma cutting machines
Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B 0
Our Services
  • Structural steel fabrication, painting, galvanizing, pre-assembly
  • Designing, fabrication and installation for prefabricated steel structure buildings
  • Deepening or designing fabrication drawings based on your architectural plans
  • Engineering consulting services
Packing and Transport

All components are packed for ocean transportation in 40'HQ containers. Our skilled workers use cranes and forklifts to prevent damage during loading.

Curved Structural Steel Beam for Arch Roof Buildings Q235B Q355B 1
How to Quote

Please provide the following information for an accurate quote:

# Question Your Answer
1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 Snow load (max. snow height) _____kn/m2, _____mm
5 Anti-earthquake _____level
6 Brickwall needed or not If yes, 1.2m high or 1.5m high
7 Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, metal steel sheets will be used
8 Door quantity & size _____units, _____(width)mm*_____(height)mm
9 Window quantity & size _____units, _____(width)mm*_____(height)mm
10 Crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
