Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity

Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity
Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity
Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity

Large Image :  Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV,ISO
Model Number: Ruly0043
Payment & Shipping Terms:
Minimum Order Quantity: 50 Ton
Price: USD900-USD1500 Per Ton
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 2000 Ton Per Month
Contact Now

Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity

Description
Features: Industrial Steel Buildings Application: Heavy Industrial Steel Structure Workshop
Raw Steel Material: Q235B, Q355B, ASTM A36, Surface Treatment: Painting Or Hot-dip Galvanize
Service Life: 50 Years Wall And Roof: Glass Wool Sandwich Panel
Columns And Beam: H Section Column&Beam, Latticed Column Service: Design,Fabrication, Installation
Highlight:

industrial steel structure

,

industrial metal buildings

Industrial Steel Buildings / Heavy Engineering Steel Structure Workshop Construction
Product Specifications
Application Heavy industrial steel structure workshop
Features Industrial Steel Buildings
Raw steel material Q235B, Q355B, ASTM A36
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof Glass wool sandwich panel
Columns and Beam H Section Column & Beam, Latticed column
Service Design, Fabrication, Installation
Project Overview

This heavy engineering steel structure workshop is designed for oil & chemical equipment production line with a building area of 23,000 square meters. The structure features a height of 33.3m and accommodates a mega overhead crane with 600-ton capacity, requiring 5500 tons of fabricated steel structure.

Workshop Specifications
Name Heavy Industrial Steel Structure Buildings Heavy Engineering Steel Workshop
Structure Type Portal frame, multi ridge
Dimensions 211m (Length) × 104m (Width)
Eave Height 33.3m
Span 38m + 36m + 30m
Steel Structure Quantity 5500 Ton
Overhead Crane Capacity One 600/120t; Two 200/60t
Crane Beam Section Height 2.5m and 4.0m
Column & Beam H-section steel, latticed column, honeycomb beam
Roof & Wall Panel Glass wool sandwich panel
Door Sliding door
Window Ribbon Skylight
Main Steel Frame Structure Components
Main steel structure H-section steel, latticed column, honeycomb beam: Raw steel material is Q345, alkyd painting, two primary painting, two finish painting
High strength bolt Grade 10.9
Turn buckle bolt M20+2, steel Q235, processing
Anchor bolt Steel Q235, processing
Ordinary bolt Galvanized bolt
Batter brace Φ32*2.5, Φ12 round steel bar Q235, process and painted (alkyd painting)
Fittings & accessories Nails, glue etc.
Project Documentation
Large Latticed Steel Column Transport
Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity 0
Steel Beam Lifting Process
Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity 1
Crane Beam Fabrication
Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity 2
Steel Designing & Detailing
Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity 3
Packing & Loading

All structure components, panels, bolts and accessories are packed with standard packaging suitable for ocean transportation and loaded into 40'HQ containers.

Heavy Industrial Steel Structure Workshop with 600 Ton Crane Capacity 4
Our Advantages
  • Professional design team capable of creating custom drawings or calculating steel quantities
  • Skilled fabrication team with advanced equipment and project-specific production schedules
  • One-stop service with integrated project proposals based on extensive experience
  • Quality control team ensuring products and services meet specifications
  • Comprehensive after-sales service including maintenance support
Quotation Requirements

Please provide the following information for an accurate quote:

1 Location (where will be built?) _____country, area
2 Size: length × width × height _____mm × _____mm × _____mm
3 Wind load (max. wind speed) _____kn/m², _____km/h, _____m/s
4 Snow load (max. snow height) _____kn/m², _____mm
5 Anti-earthquake _____level
6 Brickwall needed or not If yes, 1.2m high or 1.5m high
7 Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels; if not, metal steel sheets
8 Door quantity & size _____units, _____(width)mm × _____(height)mm
9 Window quantity & size _____units, _____(width)mm × _____(height)mm
10 Crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
