Product Details:
|
Application: | Prefabricated Workshop Buildings,Industrial Steel Frame Buildings | Usage: | Steel Structure Workshop, Metal Warehouse, Factory Buildings |
---|---|---|---|
Type: | Steel Structure Workshop | Raw Steel Material: | Q235B, Q355B |
Surface Treatment: | Painting Or Hot-dip Galvanize | Service Life: | 50 Years |
Wall And Roof: | EPS Sandwich Panel | Columns And Beam: | H Section Column&Beam |
Highlight: | steel structure factory building,metal workshop building |
Attribute | Value |
---|---|
Application | Prefabricated Workshop Buildings, Industrial Steel Frame Buildings |
Usage | Steel Structure Workshop, Metal Warehouse, Factory Buildings |
Type | Steel Structure Workshop |
Raw steel material | Q235B, Q355B |
Surface treatment | Painting or Hot-dip Galvanize |
Service life | 50 Years |
Wall and Roof | EPS sandwich panel |
Columns and Beam | H Section Column & Beam |
Covered Area | 9000m² |
Structure Type | Portal frame, single ridge |
Dimensions (L×W×H) | 150m × 60m × 10m (eave height) |
Roof Slope | 10% |
Gable Wall Column Spacing | 7.5m |
Roof Material | 75mm EPS sandwich panel |
Wall Material | 75mm EPS sandwich panel |
Door Type | Sliding door |
Window Type | Ribbon Skylight |
Height Difference (Indoor/Outdoor) | 300mm |
Component | Specification | Material | Treatment |
---|---|---|---|
Column | H shape, Box, Steel pipe, Hot rolled sheet | Q235B, Q345B | Paint or Hot dip galvanized |
Beam | H shape, Steel Truss, Hot rolled sheet | Q235B, Q345B | Paint or Hot dip galvanized |
Bracing | Steel rod, Steel pipe, Angle steel | Q235B, Q345B | - |
Purlin | C or Z shape, Thickness: 1.8mm~3.0mm | Q235B, Q346B | Hot dip galvanized |
Wall/Roof Panel | EPS, Rock wool, PU, Glass wool Sandwich panel or Single sheet | Steel T=0.426~0.8mm, Insulation T=50~150mm | Alu-zinc 150g, Fluorocarbon paint |
Door | Sliding or rolling door | Steel or Aluminum sheet, T=1.0~1.5mm | Paint or Hot dip galvanized |
Window | Alloy-Glass, Aluminium alloy-shutter | T=1.0~2.0mm | Alloy |
Lighting Panel | FRP, T=1.5mm or T=1.8mm | Coefficient of thermal expansion: 2.2x10-5/cm/cm/℃ | Light transmittance 85% |
Ventilator | Turbine ventilator, and electric type | Steel, stainless steel, PC | Paint or Hot dip galvanized, 304 |
Gutter | Galvanized or stainless steel plate | T=2.0mm | Hot dip galvanized, 304 |
Downpipe | PVC pipe, Color steel pipe T=0.5mm | Φ110, 160, 200 | Paint |
Bolt | Ordinary, high strength | 10.9S, 4.8s | Hot dip galvanized |
Anchor bolt | Steel rod M24, M27, M30 | Q235B | - |
