Industrial Steel Frame Workshop with Crane Q235B Q355B Construction

Large Image : Industrial Steel Frame Workshop with Crane Q235B Q355B Construction

Product Details:

Place of Origin:	China
Brand Name:	Ruly Steel
Certification:	SGS, BV, ISO
Model Number:	Ruly0304

Payment & Shipping Terms:

Minimum Order Quantity:	500 Square Meter
Price:	USD29-USD99 Per Square Meter
Packaging Details:	As request
Delivery Time:	30 Days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	20000 Square Meter Per Month

Contact Now

Industrial Steel Frame Workshop with Crane Q235B Q355B Construction

Description

Features:	Metal Workshop Construction	Application:	Industrial Steel Frame Buildings,
Type:	Steel Frame Structure Workshop With Crane	Raw Steel Material:	Q235B, Q355B, ASTM A36
Service Life:	50 Years	Wall And Roof:	Rock Wool
Surface Treatment:	Painting	Working Scope:	Design,Fabrication, Installation
Highlight:	10mm Industrial Steel Frame Buildings , 8mm Industrial Steel Frame Buildings , 10mm Metal Workshop Construction

Steel 8mm/10mm Industrial Steel Frame Buildings Metal Workshop Construction

Product Specifications

Attribute	Value
Application	Industrial Steel Frame Buildings
Features	Metal Workshop Construction
Type	Steel Frame Structure Workshop With Crane
Raw steel material	Q235B, Q355B, ASTM A36
Service life	50 Years
Wall and Roof	Rock wool
Surface treatment	Painting
Working scope	Design, Fabrication, Installation

Project Overview

Industrial Steel Frame Buildings / Industrial Metal Workshop Construction. The main steel frame structure consists of welded H-section steel columns and beams connected by high strength bolts. All steel structures are fabricated in our factory. Welded steel structure offers excellent rigidity and light weight, providing favorable conditions for production, transportation and installation.

Material Specifications

Component	Specification	Details
Steel Frame	H section steel	Q235/Q355 steel 8mm/10mm
Welding	Automatic submerged arc welding
Rust removal	Sand blasting
Surface finish	Alkyd paint or galvanized
Intensive bolt	M20, Grade 10.9
Supporting System	Angle brace	L50x4, Steel Q235, processed and painted
Horizontal brace	Φ20, Steel Q235, processed and painted
Column brace	Φ20, Steel Q235, processed and painted
Tie rod	Φ89*3, Steel Q235, processed and painted
Ordinary bolt	M12 Galvanized bolt
Roof	Purlin	C160602.5, Steel Q235, galvanized and painted
Roof panel	Sandwich panel or corrugated steel sheet
Sky light	6mm thick PVC
Accessories	Glass cement, self-tapping screws, etc.
Edge cover	0.4mm steel sheet profile trimming
Gutter	0.4mm thick sheet steel profile or galvanized sheet
Down pie	Φ110PVC
Walls	Purlin	C160602.5, Steel Q235, painted
Wall	Sandwich panel or corrugated steel plate
Ventilation	Ventilation ball
Doors & windows	Rolling door/sliding door PVC/alu/steel/window

Key Advantages

#	Feature	Description
1	High strength and light weight	Steel offers excellent strength-to-weight ratio, enabling large span structures with relatively small weight.
2	Good plasticity and toughness	Steel's plasticity prevents sudden failure under overload, while its toughness makes structures more adaptable to dynamic loads.
3	High degree of industrialization	Components are precision-made in specialized factories, ensuring consistent quality.
4	Simple construction	Prefabricated components enable fast on-site assembly, significantly reducing construction time.
5	Wind resistance	Lightweight yet strong structure with excellent overall rigidity and deformation capability.
6	Cost efficiency	Reduced foundation requirements and fast construction lead to better economic benefits than concrete structures.
7	Recyclable	Steel is fully recyclable, minimizing environmental impact during construction and demolition.

Our Manufacturing Facility

We operate three production lines for steel structure fabrication, equipped with advanced machinery including plasma cutting machines to ensure precision manufacturing for international projects.

Installation Process

We provide detailed construction drawings for each project and offer comprehensive installation guidance. Our team can either dispatch engineers to supervise on-site installation or handle the complete installation process with our skilled construction team.

Packaging and Shipping

All structural components, panels, bolts and accessories are securely packed in standard ocean transport packaging and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts to carefully load goods at our factory, ensuring no damage during transportation.

Advanced Technologies

Heat preservation and energy saving: Special insulating materials are used in exterior and interior walls for optimal thermal efficiency.

Fire protection: Our steel structures meet fire rating requirements with one-hour fire prevention capability.

Sound insulation: Glass wool insulation effectively prevents airborne sound transmission.
