|Application:||Prefabricated Workshop Buildings Steel Frame Structure Modern Steel Structures||Usage:||Steel Structure Workshop|
|Type:||Steel Structure Workshop||Working Scope:||Design,Fabrication, Installation|
|Raw Steel Material:||Q235B, Q355B||Surface Treatment:||Painting Or Hot-dip Galvanize|
|Wall And Roof:||Glass Wool||Service Life:||50 Years|
Prefabricated Steel Structure Feed Factory,
Galvanized Steel Structure Feed Factory
Prefabricated Steel Structure Feed Factory Steel Structure Office Building
Prefabricated Steel Structure Feed Factory Steel Structure Office Building is used for automobile spare parts store. H steel truss beam is connected to be the roof. The truss beam in the truss structure is a lattice-like beam structure. Compared with the solid web stee beam, the truss beam are arranged in the upper and lower ends due to the concentrated tension and compression sections, so that the internal force arm is increased, so that the same material amount is used to achieve greater bending strength.Truss structures are commonly used in large-span buildings, exhibition halls, stadiums, and bridges.
|Main Steel Frame System|
|Main structure||H section steel Q355, alkyd painting, two primary painting, two finish painting.|
|Roof purlin||XZ160*60*20*2.5, galvanized|
|Wall purlin||XZ160*60*20*2.5, galvanized|
|Intensive bolt||Grade 10.9|
|Turn buckle bolt||M20+2, steel Q235, processing|
|Anchor bolt||M24, steel Q235, processing|
|Ordinary bolt||Galvanized bolt M20|
|Ordinary bolt||Galvanized bolt M12|
|Brace nut||Galvanized bolt M12|
|Cross brace||Φ20 round steel bar Q235, process and painted (alkyd painting)|
|Angle brace||L50*5 angle steel Q235, process and painted (alkyd painting)|
|Column bracing||Φ25 round steel bar Q235, process and painted (alkyd painting)|
|Tie bar||Φ127*3 steel pipe Q235, process and painted (alkyd painting)|
|Batter brace||Φ32*2.5, Φ12 round steel bar Q235, process and painted (alkyd painting)|
|Wall & Roof System|
|Roof panel||PU sandwich panel|
|Wall panel||PU sandwich panel|
|Edge cover||0.5mm color plate, angle Alu.|
|Fittings & accessories||Nails, glue etc.|
|Unpowered ventilator||Diameter Φ600, stainless steel|
|Sky lighting band||1.2mm FRP, double layer|
|Sliding door||sandwich panel door|
|Roof drainage system|
|Gutter||0.5mm color steel plate|
|Rainspout pipes||Φ110 PVC pipe|
1.Light-weightness and more resistance to earthquakes and strong winds.
2.Sustainability and less lifecycle cost thanks to low maintenance costs and highest quality materials, such as galvanized steel.
3.Shorter construction period with the help of modularity and error-free prefabrication of building elements.
4.Environment-friendly thanks to reusable steel members and minimized wastes by efficient usage of materials in the factory.
5.Functionality, provided by relocatable, replaceable and load carrying walls and efficient usage of the space.
Method 1: We provide shop drawing before installation.
Method 2: If you still don't know how to install, We will teach you the installation in our factory. when necessary , we will assemble a sample steel structure building for you.
All the structure components, panels,bolts and sort of accessories will bewell packed with standard package suitable ocean transportation and loaded into 40’HQ.
All the products are loaded at the loading site of our factory using crane and forklift by our skilled workers,who will prevent the goods to be damaged.
We can produce light and heavy steel structure buildings, such as warehouse, workshop, storage, construction materials, high rise steel office buiding, factory , plant, exhibition hall, steel tile.
The following question we need to know before making the price. Just feel free to fill what you know.
|1||Location (where will be built?)||_____country, area|
|3||wind load (max. wind speed)||_____kn/m2, _____km/h, _____m/s|
|4||snow load (max. snow height)||_____kn/m2, _____mm|
|6||brickwall needed or not||If yes, 1.2m high or 1.5m high|
|7||thermal insulation||If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; . if not, the metal steel sheets will be ok. The cost of the latter will be much
lower than that of the former
|8||door quantity & size||_____units, _____(width)mm*_____(height)mm|
|9||window quanity & size||_____units, _____(width)mm*_____(height)mm|
|10||crane needed or not||If yes, _____units, max. lifting weight____tons; max. lifting height _____m|
