Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop

Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop
Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop

Large Image :  Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV,ISO
Model Number: Ruly0053
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20000 Square Meter Per Month

Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop

Description
Application: Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop Usage: Steel Structure Workshop, Metal Warehouse, Factory Buildings, Garment Factory, Clothes Plant
Type: Steel Structure Workshop Working Scope: Design,Fabrication, Installation
Raw Steel Material: Q235B, Q355B Surface Treatment: Painting Or Hot-dip Galvanize
Service Life: 50 Years Wall And Roof: Glass Wool
High Light:

prefab steel buildings

,

metal workshop building



Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop



General



Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop is used for automobile spare parts store. H steel truss beam is connected to be the roof. The truss beam in the truss structure is a lattice-like beam structure. Compared with the solid web stee beam, the truss beam are arranged in the upper and lower ends due to the concentrated tension and compression sections, so that the internal force arm is increased, so that the same material amount is used to achieve greater bending strength.Truss structures are commonly used in large-span buildings, exhibition halls, stadiums, and bridges.





Project information for Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop



Name Prefabricated Steel Truss Roof Steel Workshop
Structure Type portal frame, two ridges, two spans with office and storeroom building
Length 200m
Width 175m
Eave Height 15m
Roof Slope flat
Gable Wall Column Spacing 7.5m
Roof

75 mm thick PU sandwich panel

Wall 75 mm thick PU sandwich panel
Door Sliding door
Window Ribbon Skylight
Height difference between indoor and outdoor 300mm



Main parts of the steel structures and technical parameters



Main Steel Frame System
Main structure H section steel Q355, alkyd painting, two primary painting, two finish painting.
Roof purlin XZ160*60*20*2.5, galvanized
Wall purlin XZ160*60*20*2.5, galvanized
Intensive bolt Grade 10.9
Turn buckle bolt M20+2, steel Q235, processing
Anchor bolt M24, steel Q235, processing
Ordinary bolt Galvanized bolt M20
Ordinary bolt Galvanized bolt M12
Brace nut Galvanized bolt M12
Bracing System
Cross brace Φ20 round steel bar Q235, process and painted (alkyd painting)
Angle brace L50*5 angle steel Q235, process and painted (alkyd painting)
Column bracing Φ25 round steel bar Q235, process and painted (alkyd painting)
Tie bar Φ127*3 steel pipe Q235, process and painted (alkyd painting)
Batter brace Φ32*2.5, Φ12 round steel bar Q235, process and painted (alkyd painting)
Wall & Roof System
Roof panel  PU sandwich panel
Wall panel PU sandwich panel
Edge cover 0.5mm color plate, angle Alu.
Fittings & accessories Nails, glue etc.
Unpowered ventilator Diameter Φ600, stainless steel
Sky lighting band 1.2mm FRP, double layer
Sliding door sandwich panel door
Roof drainage system
Gutter 0.5mm color steel plate
Rainspout pipes Φ110 PVC pipe



Truss roof beam fabrication in our steel structure produciton line



Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop 0



How to install

Method 1:  We provide shop drawing before installation.

Method 2:  If you still don't know how to install, We will teach you the installation in our factory. when necessary , we will assemble a sample steel structure building for you.

Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop 1



Packing and transport



All the structure components, panels,bolts and sort of accessories will bewell packed with standard package suitable ocean transportation and loaded into 40’HQ.

All the products are loaded at the loading site of our factory using crane and forklift by our skilled workers,who will prevent the goods to be damaged.

Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop 2

What we do



We can produce light and heavy steel structure buildings, such as warehouse, workshop, storage, construction materials, high rise steel office buiding, factory , plant, exhibition hall, steel tile.



How to quote



The following question we need to know before making the price. Just feel free to fill what you know.

1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 snow load (max. snow height) _____kn/m2, _____mm
5 anti-earthquake _____level
6 brickwall needed or not If yes, 1.2m high or 1.5m high
7 thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; . if not, the metal steel sheets will be ok. The cost of the latter will be much
lower than that of the former
8 door quantity & size _____units, _____(width)mm*_____(height)mm
9 window quanity & size _____units, _____(width)mm*_____(height)mm
10 crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m

Contact Details
Qingdao Ruly Steel Engineering Co.,Ltd

Contact Person: steven

Tel: 0086-18661691560

Send your inquiry directly to us (0 / 3000)
