Prefab Steel Warehouse Structure Q235B Q355B ASTM A36

Large Image : Prefab Steel Warehouse Structure Q235B Q355B ASTM A36

Product Details:

Place of Origin:	China
Brand Name:	Ruly Steel
Certification:	SGS, BV, ISO
Model Number:	Ruly0315

Payment & Shipping Terms:

Minimum Order Quantity:	300 Square Meter
Packaging Details:	As request
Delivery Time:	15 ~ 20 Days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	20000 Square Meter Per Month

Contact Now

Prefab Steel Warehouse Structure Q235B Q355B ASTM A36

Description

Application:	Prefab Steel Structure Warehouse	Type:	Steel Structure Warehouse
Raw Steel Material:	Q235B, Q355B, ASTM A36	Working Scope:	Design,Fabrication, Installation
Wall And Roof:	Steel Cladding Sheet	Service Life:	50 Years
Surface Treatment:	Painting	Standard:	AISC, ASTM, BS, DIN, GB, JIS
Highlight:	Fabrication Prefab Steel Warehouse , QB355 Prefab Steel Warehouse , QB355 Construction Steel Structure

Fabrication Prefab Steel Warehouse With QB355 Construction Steel Structure

Product Attributes

Attribute	Value
Application	Prefab Steel Structure Warehouse
Type	Steel Structure Warehouse
Raw steel material	Q235B, Q355B, ASTM A36
Working scope	Design, Fabrication, Installation
Wall and Roof	Steel cladding sheet
Service life	50 Years
Surface treatment	Painting
Standard	AISC, ASTM, BS, DIN, GB, JIS

Product Description

Steel structure components are mainly composed of steel beams, steel columns, steel trusses and other components made of section steel and steel plates. These components are typically connected by welding seams, bolts or rivets to create factory buildings, warehouses, office buildings, and residences.

The steel structure building system offers significant advantages including light deadweight, factory production, fast installation, short construction period, excellent seismic performance, faster investment recovery, and minimal environmental pollution. Compared to reinforced concrete structures, steel structures excel in "high, big, light" applications and are widely used in construction projects globally.

Component Materials

Steel Frame	H section steel \| Q235/Q345 steel plate thickness: 8-30mm
Welding	Automatic submerged arc welding
Rust removal	Sand blasting
Surface finish	Alkyd paint or galvanized
Intensive bolt	M20, Grade 10.9
Supporting System	Angle brace: L50x4, Steel Q235, processed and painted Horizontal brace: Φ20, Steel Q235, processed and painted Column brace: Φ20, Steel Q235, processed and painted Tie rod: Φ89*3, Steel Q235, processed and painted
Ordinary bolt	M12 Galvanized bolt
Roof	Purlin: C160602.5, Steel Q235, galvanized and painted Roof panel: Sandwich panel or corrugated steel sheet Sky light: 6mm thick PVC Accessories: Glass cement, self-tapping screws, etc. Edge cover: 0.4mm steel sheet profile trimming Gutter: 0.4mm thick sheet steel profile or galvanized sheet Down pie: Φ110PVC
Walls	Purlin: C160602.5, Steel Q235, painted Wall: Sandwich panel or corrugated steel plate Accessories: Glass cement, self-tapping screws, etc. Edge cover: 0.4mm steel sheet profile trimming Ventilation: Ventilation ball Doors & windows: Rolling door/sliding door PVC/alu/steel/window

Product Testing

Main Characteristics of Steel Structure

Super Aseismatic: Cold formed steel members provide aseismatic grade up to 8
Wind Resistance: High strength structure can resist winds up to 50m/s
Durable: Painted or galvanized steel offers 50-70 year lifespan
Heat Insulation: Sandwich panels prevent "cold bridge" effect
Environment Protection: Minimal construction waste with 100% recyclable materials
Easy and Fast Build: 300m² structure can be completed in 30 days by 5 workers

Drawings & Quotation

Customized designs are available. Our design team can create solutions based on your specific project requirements. For accurate quotations and drawings, please provide your project details.
