H Beam Steel Structure Warehouse Q235B Q355B ASTM A36

H Beam Steel Structure Warehouse Q235B Q355B ASTM A36
H Beam Steel Structure Warehouse Q235B Q355B ASTM A36
H Beam Steel Structure Warehouse Q235B Q355B ASTM A36 H Beam Steel Structure Warehouse Q235B Q355B ASTM A36 H Beam Steel Structure Warehouse Q235B Q355B ASTM A36 H Beam Steel Structure Warehouse Q235B Q355B ASTM A36 H Beam Steel Structure Warehouse Q235B Q355B ASTM A36 H Beam Steel Structure Warehouse Q235B Q355B ASTM A36 H Beam Steel Structure Warehouse Q235B Q355B ASTM A36

Large Image :  H Beam Steel Structure Warehouse Q235B Q355B ASTM A36

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0318
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

H Beam Steel Structure Warehouse Q235B Q355B ASTM A36

Description
Application: Structural Steel Frame Construction Raw Steel Material: Q235B, Q355B, ASTM A36
Columns And Beam: H Section Column&Beam Shot Blasting Level: Sa 2.5
Service Life: 50 Years Wall And Roof: Rock Wool
Surface Treatment: Painting Working Scope: Design,Fabrication, Installation
Highlight:

H Beam Steel Frame Construction

,

ASTM Steel Frame Construction

,

H Beam Steel Structure Warehouse

H Beam Structural Steel Frame Construction Steel Structure Warehouse
Product Specifications
Application Structural Steel Frame Construction
Raw steel material Q235B, Q355B, ASTM A36
Columns and Beam H Section Column & Beam
Shot blasting level Sa 2.5
Service life 50 Years
Wall and Roof Rock wool
Surface treatment Painting
Working scope Design, Fabrication, Installation
Product Description
Our structural steel frame construction warehouse is composed of high-quality steel materials, making it one of the most reliable building structure types. The structure primarily consists of steel plates, columns, and trusses, connected through welding, bolts, or rivets. Known for its lightweight properties and simple construction, it's ideal for various applications including factories, warehouses, and commercial buildings.
Detailed Specifications
Component Specification
Main Steel Frame
Column Q235, Q355 welded H section steel
Beam Q235, Q355 welded H section steel
Secondary Frame
Purlin Q235 C and Z purlin
Knee brace Q235 angle steel
Tie rod Q235 circular steel pipe
Brace A235 round bar
Vertical and horizontal support Q235 angle steel, round bar or steel pipe
Maintenance System
Roof panel EPS sandwich panel/glass fiber sandwich panel/rock wool sandwich panel/Pu sandwich panel/steel sheet
Wall panel Sandwich panel/corrugated steel sheet
Accessories
Window Aluminium alloy window/PVC window/sandwich panel window
Door Sliding sandwich panel door/rolling metal door/personal door
Rainspout PVC
Live load on roof 120kg/sqm (color steel panel surrounded)
Wind resistance grade 12 grades
Earthquake-resistance 8 grades
Structure usage Up to 50 years
Finishing options Vast array of colors and textures available
Paint options Alkyd painting, two primary painting, two finish painting (Gray paint, red paint, white paint, epoxy zinc etc.) or galvanized
Our Steel Structure Production Line
H Beam Steel Structure Warehouse Q235B Q355B ASTM A36 0
Design Model
H Beam Steel Structure Warehouse Q235B Q355B ASTM A36 1
Packing and Transport
All structural components, panels, bolts, and accessories are packed with standard packaging suitable for ocean transportation and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts at our factory loading site to ensure safe handling and prevent damage during transportation.
H Beam Steel Structure Warehouse Q235B Q355B ASTM A36 2
Request a Quote
Please provide the following information for an accurate quotation:
1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 Snow load (max. snow height) _____kn/m2, _____mm
5 Anti-earthquake _____level
6 Brickwall needed or not If yes, 1.2m high or 1.5m high
7 Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, the metal steel sheets will be ok
8 Door quantity & size _____units, _____(width)mm*_____(height)mm
9 Window quantity & size _____units, _____(width)mm*_____(height)mm
10 Crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
