Q355B Prefabricated Steel Warehouse with 50-Year Lifespan

Large Image : Q355B Prefabricated Steel Warehouse with 50-Year Lifespan

Product Details:

Place of Origin:	Qingdao,China
Brand Name:	Ruly Steel
Certification:	CE,AISC,SGS, BV, ISO,GB
Model Number:	RULYC022

Payment & Shipping Terms:

Minimum Order Quantity:	200 square meters
Price:	USD19-USD39 Per Square Meter
Packaging Details:	40HQ/Open top container
Delivery Time:	20 days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	20,000 square meters or 1,500 tons per month

Contact Now

Q355B Prefabricated Steel Warehouse with 50-Year Lifespan

Description

Features:	Prefab Steel Structure, Large Span, Multi-Floor	Raw Steel Material:	Q235B, Q355B, ASTM A36
Application:	Steel Workshop, Steel Structure Platform, Structural Roofing, Frame Part	Surface Treatment:	Painting Or Hot-DIP Galvanized
Service Life:	50 Years	Wall And Roof:	Steel Cladding Sheet,Sandwich Panel
Columns & Beams:	H-Section Steel	Shot Blasting Level:	SA 2.5
Certification:	CE, AISC, SGS, BV, ISO, GB	Installation:	Engineer Guidance On Site
Drawing:	CAD, TEKLA, 3D Model, PKPM, BIM	HS Code:	9406900090
Transport Package:	Standard Export Package Or Customer′s Requirement	Production Capacity:	30000ton/Year
Connection Form:	Bolt Connection
Highlight:	Prefabricated Steel Structure Building , Quick Assembly Steel Structure Building , Q355B Steel Structure Building

Q355B Prefabricated Steel Structure Building

Quick Assembly Warehouse for Storage

Product Specifications

Attribute	Value
Raw Steel Material	Q235B, Q355B, ASTM A36
Application	Steel Workshop, Steel Structure Platform, Structural Roofing, Frame Part
Surface Treatment	Painting or Hot-DIP Galvanized
Service Life	50 Years
Wall and Roof	Steel cladding sheet, Sandwich Panel
Columns & Beams	H-Section Steel
Shot Blasting Level	SA 2.5
Certification	CE, AISC, SGS, BV, ISO, GB
Installation	Engineer Guidance on Site
Drawing	CAD, TEKLA, 3D Model, PKPM, BIM
HS Code	9406900090
Transport Package	Standard Export Package or Customer's Requirement
Production Capacity	30000ton/Year
Features	Prefab Steel Structure, Large Span, Multi-Floor
Connection Form	Bolt Connection

Product Description

Q355B Prefabricated Steel Structure Building offers quick-assembly solutions for efficient storage needs. These steel warehouses provide superior strength and durability for industrial applications.

Key Advantages

Structural Strength: Withstands heavy loads and adverse weather conditions including wind, snow, and seismic forces
Spacious Design: Clear-span construction maximizes storage capacity without interior columns
Flexible Configuration: Easily modified and expanded to accommodate changing storage needs
Fire Resistance: Non-combustible steel construction enhances safety for stored goods
Cost-Effective: Quick construction reduces labor costs with minimal long-term maintenance
Energy Efficient: Optional insulation systems regulate temperature for reduced operational costs
Fast Construction: Prefabricated components enable rapid on-site assembly

Technical Specifications

Main Steel Frame	Column: Q235,Q355 welded H section steel Beam: Q235,Q355 welded H section steel
Secondary Frame	Purlin: Q235 C and Z purlin Knee Brace: Q235 angle steel Tie Rod: Q235 circular steel pipe Brace: A235 round bar Vertical/Horizontal Support: Q235 angle steel, round bar or steel pipe
Maintenance System	Roof Panel: EPS sandwich panel/glass fiber sandwich panel/rock wool sandwich panel/Pu sandwich panel/steel sheet Wall Panel: Sandwich panel/corrugated steel sheet
Accessories	Window: Aluminium alloy window/PVC window/sandwich panel window Door: Sliding sandwich panel door/rolling metal door/personal door Rainspout: PVC
Performance	Live Load on Roof: 120kg/sqm (color steel panel surrounded) Wind Resistance: Grade 12 Earthquake Resistance: Grade 8 Structure Usage: Up to 50 years
Finishing Options	Vast array of colors and textures available Paint Options: Alkyd painting, two primary painting, two finish painting (Gray paint, red paint, white paint, epoxy zinc etc.) or galvanized

Company Profile

Qingdao Ruly Steel Engineering Co., Ltd is a professional steel structure design, research, fabrication and construction company based in Qingdao, China. Our 35,000 square meter facility includes a 20,000 square meter processing plant with monthly production capacity exceeding 2000 tons.

We specialize in prefabricated steel structures including warehouses, workshops, storage sheds, garages, hangars, and commercial buildings. Our products have been exported worldwide, supported by certifications including AWS D1.1, CE, ISO 14001, ISO9001, ISO45001, AS/NZS 1554, SGS and BV.

Processing and Fabrication

Our Service

Our Certifications

Packing and Loading

All structural components, panels, bolts and accessories are packed with standard ocean transportation packaging and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts to ensure damage-free loading.

Why Choose Us

Professional design team capable of custom drawings or quantity calculations
Skilled fabrication team with advanced equipment and project-specific production schedules
Comprehensive one-stop service for complete project solutions
Dedicated QC team ensuring product and service quality
Reliable after-sales support for maintenance and technical assistance

Request a Quote

Please provide the following information for an accurate quotation:

Question	Your Information
Location (where will it be built?)	_____country, area
Size: lengthwidthheight	_____mm_____mm_____mm
Wind load (max. wind speed)	_____kn/m2, _____km/h, _____m/s
Snow load (max. snow height)	_____kn/m2, _____mm
Anti-earthquake requirement	_____level
Brickwall needed or not	If yes, 1.2m high or 1.5m high
Thermal insulation requirement	If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, metal steel sheets will be used
Door quantity & size	_____units, _____(width)mm*_____(height)mm
Window quantity & size	_____units, _____(width)mm*_____(height)mm
Crane needed or not	If yes, _____units, max. lifting weight____tons; max. lifting height _____m
