Product Details:
|
Features: | Pre Building Structure | Type: | PEB Steel Buildings |
---|---|---|---|
Application: | Logistics Warehouse, Workshop, Plant | Raw Steel Material: | Q235B, Q355B |
Surface Treatment: | Painting | Service Life: | 50 Years |
Wall And Roof: | Sandwich Panel | Working Scope: | Design,Fabrication, Installation |
Highlight: | Prefabricated Milk Processing Plant,Prefabricated Q355B Steel Structure Building |
Attribute | Value |
---|---|
Features | Pre Building Structure |
Type | PEB Steel Buildings |
Application | Logistics warehouse, workshop, plant |
Raw steel material | Q235B, Q355B |
Surface treatment | Painting |
Service life | 50 Years |
Wall and Roof | Sandwich panel |
Working scope | Design, Fabrication, Installation |
Item | Specification |
---|---|
Main Pillar & Beams | Q355B |
Roof Purlins | C200*70*20*2.5 Galvanize |
Tie Bar | Φ114*4 |
Pillar Supporters | Φ20 |
Tie rod | Φ12,Φ32*2.5 |
Kneebracing | L50*4 |
Foundation bolt | M24 |
General Bolts | C Grade |
Bolt screw | Φ19 |
High Strengthened Bolts | 10.9 Grade |
Roof Panel | 0.5mm Galvanized Steel Plate |
Ribbon skylight | 1.2mm FRP |
Floor Steel deck | 1.00 mm steel plate |
Doors | Sliding door |
Windows | Steel windows |
Gutters | 3mm thick galvanized steel |
Edge and corner wrapping | 0.5mm Galvanized Steel Plate |
Down pipe | Φ140PVC |
Product | H Steel Beam, Columns, Piperack Supporting Steel, Channel steel |
Raws Steel Material | Q235 Q345 A36 A53 S235JR SS400 |
Welding Technic | GB, AWS D1.1 |
Shaped Steel | Hot rolled & welded |
Section | H shaped |
Rust-protection | Shot blasting, then paint Alkyd paiting, two primary painting, two finish painting |
Application | Steel Frame Strucuture, Steel Supporting |
Web Thickness | 8-55mm |
Web Width | 50-600mm |
Flange Thickness | 5-55mm |
Flange Width | 100-2500mm |
Length | 1-12m |
Custom Order | Yes |
Packing | Bundle etc. |
Our company specializes in light and heavy steel structure engineering, offering integrated design, production, and construction services. Certified under ISO9001:2008 quality management system, we maintain rigorous quality control throughout all project phases.
With extensive experience in constructing large steel structure workshops, warehouses, car showrooms, stadiums, and landscape structures, we have earned recognition for our excellent product quality and engineering standards.
