Q235B Q355B PEB Steel Building Frame for Warehouse Workshop

Q235B Q355B PEB Steel Building Frame for Warehouse Workshop
Q235B Q355B PEB Steel Building Frame for Warehouse Workshop
Q235B Q355B PEB Steel Building Frame for Warehouse Workshop Q235B Q355B PEB Steel Building Frame for Warehouse Workshop Q235B Q355B PEB Steel Building Frame for Warehouse Workshop Q235B Q355B PEB Steel Building Frame for Warehouse Workshop Q235B Q355B PEB Steel Building Frame for Warehouse Workshop Q235B Q355B PEB Steel Building Frame for Warehouse Workshop Q235B Q355B PEB Steel Building Frame for Warehouse Workshop

Large Image :  Q235B Q355B PEB Steel Building Frame for Warehouse Workshop

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0094
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Q235B Q355B PEB Steel Building Frame for Warehouse Workshop

Description
Features: Pre Engineered Building Structure Application: Warehouse, Workshop, Plant
Type: PEB Steel Buildings Warehouse Raw Steel Material: Q235B, Q355B
Surface Treatment: Painting Service Life: 50 Years
Wall And Roof: Sandwich Panel Working Scope: Design,Fabrication, Installation
Highlight:

Q355B PEB Steel Buildings

,

Q235B PEB Steel Buildings

,

Q235B PEB Steel Warehouse

Q235B Q355B PEB Steel Buildings Warehouse Workshop Frame
Product Specifications
Attribute Value
Application warehouse, workshop, plant
Features Pre Engineered Building Structure
Type PEB Steel Buildings Warehouse
Raw steel material Q235B, Q355B
Surface treatment Painting
Service life 50 Years
Wall and Roof Sandwich panel
Working scope Design, Fabrication, Installation
Project Applications
  • Workshop, warehouse, plant, storage
  • Steel web frame structure
  • High rise building project
  • Other steel structure buildings
Material Specifications and Technical Parameters
No. Item Details
1 Material Carbon structural steel
2 Produce Lead time Normally 45 days after down payment, varies by quantity
3 Quality Certification Factory quality certificate, third-party available upon request
4 Dimensions Length H beam: 4000-15000mm
5 Thickness Web plate: 6-32mm
6 Thickness Wing plate: 6-40mm
7 Height 200-1200mm
8 Color Customizable to customer requirements
9 Size MOQ 1000 m², width × length × eave height
10 Main components Base Cement and steel foundation bolts
11 Main frame H Steel beam, Q235 Q345 steel H beam and columns, painted or galvanized, box steel, galvanized C section or steel pipe
12 Secondary frame Galvanized C or Z purlin, steel bracing, tie bar, knee brace, flashing etc.
13 Material Q235B, Q345B or others as requested (ASTM, BSEN, DIN, IPE, AISI, JIS)
14 Purlin C or Z purlin: Size from C120~C320, Z100~Z20
15 Column X-type, tree type, lattice, Cross, Box etc.
16 Bolt Plain bolt and High-strength bolt
17 Roof & wall PU sandwich panel, Rockwool sandwich panel or Corrugated steel sheet
18 Canopy Steel sheet, PU sandwich panel, Rockwool sandwich panel
19 Door Sliding or rolling door
20 Window Aluminium alloy window
21 Surface Two layers of rust-proof painting or Hot Dip Galvanized
22 Sheet 0.5mm or 0.6mm galvanized sheet
23 Accessories Semi-transparent skylight belts, Ventilators, down pipe, Galvanized gutter, Trim, flashing, etc
24 Finishing options Various colors and textures available, Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) or Galvanized
Our Steel Structure Production Line
Q235B Q355B PEB Steel Building Frame for Warehouse Workshop 0
Installation Process
We provide construction drawings for each project before installation. Our engineers can guide installation on site or our construction team can handle the complete installation.
Q235B Q355B PEB Steel Building Frame for Warehouse Workshop 1
Packing and Transportation
All structure components, panels, bolts and accessories are packed with standard packaging suitable for ocean transportation and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts to load products carefully to prevent damage.
Q235B Q355B PEB Steel Building Frame for Warehouse Workshop 2
Request a Quote
Please provide the following information for an accurate quote:
Location (where will be built?) _____country, area
Size: length × width × height _____mm × _____mm × _____mm
Wind load (max. wind speed) _____kn/m², _____km/h, _____m/s
Snow load (max. snow height) _____kn/m², _____mm
Anti-earthquake _____level
Brickwall needed or not If yes, 1.2m high or 1.5m high
Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, metal steel sheets will be used (lower cost)
Door quantity & size _____units, _____(width)mm × _____(height)mm
Window quantity & size _____units, _____(width)mm × _____(height)mm
Crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
