Prefabricated Steel Structure Warehouse H Beam Frame 50 Years Life

Large Image : Prefabricated Steel Structure Warehouse H Beam Frame 50 Years Life

Product Details:

Place of Origin:	China
Brand Name:	Ruly Steel
Certification:	CE, AISC,ISO,SGS, BV
Model Number:	RULYZ002

Payment & Shipping Terms:

Minimum Order Quantity:	500 Square Meter
Price:	USD29-USD99 Per Square Meter
Packaging Details:	As request
Delivery Time:	30 Days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	20000 Square Meter Per Month

Contact Now

Prefabricated Steel Structure Warehouse H Beam Frame 50 Years Life

Description

Features:	Large Steel Frame Structure Metal Buildings	Application:	Steel Structure Warehouse
Type:	Prefabricated Steel Frame Buildings	Raw Steel Material:	Q235B, Q355B
Surface Treatment:	Painting	Columns And Beam:	H Section Column&Beam
Service Life:	50 Years	Usage:	Steel Structure Warehouse，Steel Construction
Highlight:	Galvanized Prefab Structural Steel Buildings , Q355B Prefab Structural Steel Buildings , Column Prefab Steel Structure Warehouse

Galvanized Prefabricated Structural Steel Buildings Steel Structure Warehouse

Product Specifications

Attribute	Value
Application	Steel Structure Warehouse
Features	Large Steel Frame Structure Metal Buildings
Type	Prefabricated Steel Frame Buildings
Raw steel material	Q235B, Q355B
Surface treatment	Painting
Columns and Beam	H Section Column & Beam
Service life	50 Years
Usage	Steel Structure Warehouse, Steel construction

Product Overview

With the rapid development of economy and upgrading of building materials, steel structure products are rising rapidly. Compared with traditional building materials, the new steel structural materials are lighter, more cost-effective, more environmentally friendly and of guaranteed quality.

Steel structure warehouse is easy to assemble, easy to remove, heat insulation is also guaranteed, and light and easy to transport, the price is more affordable, the use of the warehouse area is larger, fire prevention and corrosion prevention, installation speed is faster.

Steel structure is widely used, not only to build warehouses, but also for high-rise residential buildings, stadiums, workshops and more.

Technical Specifications

No.	Item	Details
1	Material	Carbon structural steel
2	Produce Lead time	Normally 45 days after down payment, also according to quantity
3	Quality Certification	Quality certificate from factory, the third party by client request
4	Dimensions Length	H beam: 4000-15000mm
5	Thickness	Web plate: 6-32mm
6	Thickness	Wing plate: 6-40mm
7	Height	200-1200mm
8	Color	According to customers
9	Size	MOQ is 1000 m2, width * length * eave height
10	Main components Base	Cement and steel foundation bolts
11	Main frame	H Steel beam, Q235 Q345 steel H beam and columns, painted or galvanized, box steel, galvanized C section or steel pipe
12	Secondary frame	Galvanized C or Z purlin, steel bracing, tie bar, knee brace, flashing etc.
13	Material	Q235B, Q345B or others as buyers' requests, like: ASTM, BSEN, DIN, IPE, AISI, JIS
14	Purlin	C or Z purlin: Size from C120~C320, Z100~Z20
15	Column	X-type, tree type, lattice, Cross, Box etc.
16	Bolt	Plain bolt and High-strength bolt
17	Roof & wall	PU sandwich panel, Rockwool sandwich panel or Corrugated steel sheet
18	Canopy	Steel sheet, PU sandwich panel, Rockwool sandwich panel
19	Door	Sliding or rolling door
20	Window	Aluminium alloy window
21	Surface	Two lays of rust-proof painting or Hot Dip Galvanized
22	Sheet	0.5mm or 0.6mm galvanized sheet
23	Accessories	Semi-transparent skylight belts, Ventilators, down pipe, Galvanized gutter, Trim, flashing, etc
24	Finishing options	Vast array of colors and textures available, Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.). Or Galvanized.

Common Applications

Steel workshop, steel warehouse, steel structure plant
Steel web frame structure
Steel H-column and steel H-beam
Portal frame products
High rise building project
Other steel structure buildings

Our Service Scope

Structural steel fabrication, painting, galvanizing, pre-assembly
Designing, fabrication and installation for Prefabricated steel structure building
Deepen or design the fabrication drawing or shop drawing based on your architectural drawing and construction drawing
Engineering consulting service

Why Choose Our Steel Structures

"Quality firstly, Customer firstly" is our company principle. We obtain sound reputation because of our good quality and service. Meanwhile, we pay attention to the team work and value win-win cooperation, which would guide us much further.

Low cost - Professional design, less construction time; saving raw materials
Environmental protection - Specialized cladding materials guarantee excellent acoustic and insulation performance; no pollution; Raw material can be recycled
Comfortable and aesthetic - Higher using areas and bigger building bays afford us wider viewpoints; distinctive and elegant profiles

Project Information Required for Quotation

No.	Question	Your Answer
1	Location (where will be built?)	_____country, area
2	Size: lengthwidthheight	_____mm_____mm_____mm
3	Wind load (max. wind speed)	_____kn/m2, _____km/h, _____m/s
4	Snow load (max. snow height)	_____kn/m2, _____mm
5	Anti-earthquake	_____level
6	Brickwall needed or not	If yes, 1.2m high or 1.5m high
7	Thermal insulation	If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, the metal steel sheets will be ok
8	Door quantity & size	_____units, _____(width)mm*_____(height)mm
9	Window quantity & size	_____units, _____(width)mm*_____(height)mm
10	Crane needed or not	If yes, _____units, max. lifting weight____tons; max. lifting height _____m
