Prefab Steel Warehouse Building with Glass Wool Sandwich Panels

Large Image : Prefab Steel Warehouse Building with Glass Wool Sandwich Panels

Product Details:

Place of Origin:	China
Brand Name:	Ruly Steel
Certification:	SGS, BV, ISO
Model Number:	Ruly0186

Payment & Shipping Terms:

Minimum Order Quantity:	500 Square Meter
Price:	USD29-USD99 Per Square Meter
Packaging Details:	As request
Delivery Time:	30 Days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	20000 Square Meter Per Month

Contact Now

Prefab Steel Warehouse Building with Glass Wool Sandwich Panels

Description

Features:	Steel Structure Warehouse	Application:	Metal Storage Buildings, Prefab Structural Steel Frame Buildings, Metal Warehouse
Type:	Prefab Steel Buildings	Raw Steel Material:	Q235B, Q355B, ASTM A36
Service Life:	50 Years	Wall And Roof:	Glass Wool Sandwich Panel
Surface Treatment:	Painting	Working Scope:	Design,Fabrication, Installation
Highlight:	steel structure building , metal warehouse construction , Painting Prefab Steel Building Warehouse

Metal Storage Steel Building Warehouse / Prefab Structural Steel Frame Buildings

Product Attributes

Attribute	Value
Application	Metal Storage Buildings, Prefab Structural Steel Frame Buildings, Metal warehouse
Features	Steel Structure Warehouse
Type	Prefab Steel Buildings
Raw steel material	Q235B, Q355B, ASTM A36
Service life	50 Years
Wall and Roof	Glass wool sandwich panel
Surface treatment	Painting
Working scope	Design, Fabrication, Installation

Product Description

Steel buildings are increasingly popular in construction due to their durability, cost-effectiveness, and rapid construction time compared to conventional methods. These prefabricated steel frame buildings are ideal for commercial shops, warehouses, workshops, and logistics bases.

Project Information

Our steel buildings feature welded H-section steel columns and beams connected by high-strength bolts, all fabricated in our factory with CNC machines. Available in single span, double span, portal frame, or truss roof configurations.

Project Details

Specification	Detail
Structure Type	Portal frame, single ridge, single span
Length	150m
Width	40m
Eave Height	10m
Roof Slope	10%
Gable Wall Column Spacing	7.5m
Roof	75mm Glass wool sandwich panel
Wall	75mm Glass wool sandwich panel
Door	Sliding door
Window	Ribbon Skylight
Height difference	300mm (indoor vs outdoor)

Material Specifications

Component	Material	Specifications
Steel Frame	H section steel	Q235/Q345 steel plate thickness: 8-30mm
Welding	Automatic submerged arc welding
Surface Treatment	Sand blasting, alkyd paint or galvanized
Intensive bolt	M20, Grade 10.9
Supporting System	Angle brace	L50x4, Steel Q235, processed and painted
Horizontal brace	Φ20, Steel Q235, processed and painted
Roof Purlin	C160602.5, Steel Q235, galvanized and painted
Wall Purlin	C160602.5, Steel Q235, painted

Steel Structure Fabrication

Our factory features three production lines equipped with advanced machinery including plasma cutting machines for precise steel structure fabrication.

Our Services

Structural steel fabrication, painting, galvanizing, pre-assembly
Design, fabrication and installation of prefabricated steel structures
Shop drawing development based on architectural plans
Engineering consulting services

Quality Control

100% dimensional tolerance testing (<1mm)
20% ultrasonic welding line testing (full penetration, no faults)
20% magnetic powder testing (no bubbles or defects)
Third-party inspection assistance available
