Prefab Steel Structure Workshop Multi-Span with Crane Support

Large Image : Prefab Steel Structure Workshop Multi-Span with Crane Support

Product Details:

Place of Origin:	China
Brand Name:	Ruly Steel
Certification:	CE,AISC,SGS, BV, ISO,GB
Model Number:	RulyD0008

Payment & Shipping Terms:

Minimum Order Quantity:	200 Square Meter
Price:	USD29-USD99 Per Square Meter
Packaging Details:	As request
Delivery Time:	30 Days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	20000 Square Meter Per Month

Contact Now

Prefab Steel Structure Workshop Multi-Span with Crane Support

Description

Features:	Prefab Steel Structure,Large Span,Mezzanine,Crane	Application:	Steel Structure Workshop
Type:	Large Span Easy Assemble Steel Workshop	Raw Steel Material:	Q235B, Q355B
Surface Treatment:	Painting Or Hot-dip Galvanize	Color:	Customized
Service Life:	50 Years	Wall And Roof:	Steel Cladding Sheet,Sandwich Panel
Working Scope:	Design,Fabrication, Installation
Highlight:	Painting Prefab Steel Structure Workshop , Multi Span Steel Structure Workshop , Easy Installation Prefab Steel Structure

Prefab Steel Structure Workshop Multi Span

Product Attributes

Attribute	Value
Application	Steel Structure Workshop
Type	Large Span Easy Assemble Steel Workshop
Features	Prefab steel structure, Large Span, Mezzanine, Crane
Raw steel material	Q235B, Q355B
Surface treatment	Painting or Hot-dip Galvanize
Color	Customized
Service life	50 Years
Wall and Roof	Steel Cladding Sheet, Sandwich Panel
Working scope	Design, Fabrication, Installation

Project Overview

This prefabricated steel structure workshop features multi-span design for easy installation, dismounting, and recycling. The project includes design, fabrication, and construction services with a total construction area of approximately 39,700 square meters and steel quantity of about 3000 tons.

Key Advantages

Wide span options: Single span or Multi-span configurations
Cost-effective: Unit price range from $50/m² to $80/m²
Long lifespan: 20-50 years of service life
Rapid construction with easy installation
Environmental protection with stable, earthquake-resistant structure
Excellent waterproofing and energy conservation properties

Technical Specifications

Component	Specification
Main Frame	H section steel Q355, alkyd painting (two primary, two finish coats)
Roof Purlin	XZ1606020*2.5, galvanized
Wall Purlin	XZ1606020*2.5, galvanized
Bracing System	Various configurations including round steel bars, angle steel, and steel pipes
Wall & Roof System	Corrugated steel plate or sandwich panel options (EPS/fiber glass/rock wool/PU)
Roof Drainage	0.5mm color steel gutter with Φ110 PVC rainspout pipes

Our Manufacturing Capabilities

We operate three production lines for light/heavy H steel, BOX sections, and C/Z purlins, equipped with advanced machinery including plasma cutting machines for precision fabrication.

Installation Support

We provide comprehensive installation support including detailed shop drawings and on-site training. When necessary, we can assemble a sample structure at our factory for demonstration purposes.

Packing & Shipping

All components are packed securely for ocean transportation and loaded into 40'HQ containers using cranes and forklifts by our skilled workers to prevent damage during transit.

Why Choose Us

Professional design team for customized solutions
Skilled fabrication with advanced equipment and quality control
One-stop service from design to installation
Comprehensive after-sales support and maintenance services

Request a Quote

Please provide the following information for an accurate quotation:

Item	Details Required
1	Location (country, area)
2	Size: length × width × height (mm)
3	Wind load (max. wind speed in kn/m², km/h, or m/s)
4	Snow load (max. snow height in kn/m² or mm)
5	Anti-earthquake requirements (level)
6	Brickwall requirements (height if needed)
7	Thermal insulation specifications
8	Door quantity & size (width × height in mm)
9	Window quantity & size (width × height in mm)
10	Crane requirements (quantity, max lifting weight in tons, max height in m)
