Prefab Steel Structure Workshop Large Span with Crane Support

Large Image : Prefab Steel Structure Workshop Large Span with Crane Support

Product Details:

Place of Origin:	China
Brand Name:	Ruly Steel
Certification:	CE,AISC,SGS, BV, ISO,GB
Model Number:	RulyY0015

Payment & Shipping Terms:

Minimum Order Quantity:	500 Square Meter
Price:	USD29-USD99 Per Square Meter
Packaging Details:	As request
Delivery Time:	30 Days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	20000 Square Meter Per Month

Contact Now

Prefab Steel Structure Workshop Large Span with Crane Support

Description

Features:	Prefab Steel Structure,Large Span,Mezzanine,Crane	Application:	Steel Structure Workshop
Type:	Large Span Easy Assemble Steel Workshop	Raw Steel Material:	Q235B, Q355B
Surface Treatment:	Painting Or Hot-dip Galvanize	Service Life:	50 Years
Wall And Roof:	Steel Cladding Sheet,Sandwich Panel	Working Scope:	Design,Fabrication, Installation
Highlight:	Large Span Prefab Steel Workshop , Crane Ventilation Steel Structure Workshop , Q355B Prefab Steel Workshop

Prefab Steel Structure Workshop - Large Span, Easy Assembly with Crane Ventilation

Key Features

Prefabricated steel structure for quick assembly
Large span design for spacious interiors
Mezzanine and crane support options
Available in Q235B or Q355B steel materials
Surface treatment: Painting or Hot-dip Galvanized
50+ year service life
Customizable wall and roof options

Product Specifications

Application	Steel Structure Workshop
Type	Large Span Easy Assemble Steel Workshop
Working Scope	Design, Fabrication, Installation
Wall and Roof Materials	Steel Cladding Sheet, Sandwich Panel

Product Advantages

Environmental Protection: Uses eco-friendly materials with lower environmental impact than traditional construction
Popular Modern Solution: Preferred building material for contemporary industrial needs
Superior Insulation: Excellent thermal properties protect contents from temperature variations
Corrosion Resistance: Special treatments extend structure lifespan
Cost Effective: Competitive pricing from $50-$80/m² depending on specifications
Quick Installation: Prefabricated components enable fast assembly
Structural Stability: Earthquake resistant with excellent load-bearing capacity

Technical Specifications

Component	Specification
Main Frame	H section steel Q355, alkyd painting (two primary, two finish coats)
Roof Purlin	XZ1606020*2.5, galvanized
Wall Purlin	XZ1606020*2.5, galvanized
Bracing System	Various configurations using round steel bars, angle steel, and steel pipes
Wall & Roof Panels	Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
Ventilation	Unpowered ventilator (Diameter Φ600, stainless steel)
Lighting	1.2mm FRP skylight bands, double layer

Our Manufacturing Capabilities

We operate three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines and various types of profiling steel sheet machines with advanced equipment including plasma cutting machines.

Installation Support

Detailed shop drawings provided before installation
On-site training available at our factory
Sample structures can be assembled for demonstration

Packaging & Shipping

All components are packed for secure ocean transportation and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts to prevent damage during loading.

Why Choose Our Steel Structures?

Expert Design Team: Custom designs based on your requirements or calculations from your drawings
Skilled Fabrication: Advanced equipment and production scheduling for each project
Complete Solutions: Integrated proposals from design to installation
Quality Assurance: Professional QC team ensures specifications are met
After-Sales Support: Maintenance advice and support for steel components

Request a Quote

Please provide the following information for an accurate quotation:

Information Required	Details Needed
Project Location	Country and area where structure will be built
Dimensions	Length × Width × Height (mm)
Environmental Loads	Wind load, snow load, and earthquake resistance requirements
Insulation Needs	Type of thermal insulation required (if any)
Door/Window Specifications	Quantity and dimensions
Crane Requirements	If needed, specify quantity, lifting capacity and height
