Prefab Steel Structure Warehouse with H-Section Frame 50-Year Lifespan

Large Image : Prefab Steel Structure Warehouse with H-Section Frame 50-Year Lifespan

Product Details:

Place of Origin:	China
Brand Name:	Ruly Steel
Certification:	SGS, BV, ISO
Model Number:	Ruly0308

Payment & Shipping Terms:

Minimum Order Quantity:	300 Square Meter
Price:	USD29-USD99 Per Square Meter
Packaging Details:	Steel frame pallets and loaded into 40’HQ
Delivery Time:	30 Days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	20000 Square Meter Per Month

Contact Now

Prefab Steel Structure Warehouse with H-Section Frame 50-Year Lifespan

Description

Application:	Structural Steel Frame Building Warehouse	Type:	Steel Structure Warehouse
Raw Steel Material:	Q235B, Q355B, ASTM A36	Service Life:	50 Years
Wall And Roof:	Rock Wool	Working Scope:	Design,Fabrication, Installation
Columns & Beams:	H-section Steel	Standard:	AISC, ASTM, BS, DIN, GB, JIS
Highlight:	Prefab Structural Steel Frame Building , Q235B Structural Steel Frame Building , Prefab Steel Structure Building

Prefab Structural Steel Frame Building Warehouse Steel Structure Building

Product Attributes

Attribute	Value
Application	Structural Steel Frame Building Warehouse
Type	Steel Structure Warehouse
Raw steel material	Q235B, Q355B, ASTM A36
Service life	50 Years
Wall and Roof	Rock wool
Working scope	Design, Fabrication, Installation
Columns & Beams	H-section steel
Standard	AISC, ASTM, BS, DIN, GB, JIS

Product Description

Our prefabricated steel structure warehouse buildings feature a durable metal frame construction ideal for industrial applications like rubber tyre factories. The main framework consists of H-section columns and beams with Z-section and U-section steel components, complemented by various panel options for walls and roof.

Key Features

High-strength steel construction with 50-year service life
Material-efficient design requiring less structural material
Flexible design options to meet specific project requirements
Professional design, fabrication, and installation services
Can work with client drawings or develop custom designs

Specification of Steel Structure Material

Component	Specification
Main Steel Frame (Column)	Q235, Q355 Welded H Section Steel
Main Steel Frame (Beam)	Q235, Q355 Welded H Section Steel
Secondary Frame (Purlin)	Q235 C and Z purlin
Knee brace	Q235 Angle Steel
Tie Rod	Q235 Circular Steel Pipe
Brace	Q235 Round Bar
Vertical and Horizontal Support	Q235 Angle Steel, Round Bar or Steel Pipe
Roof Panel	EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel / Steel Sheet
Wall Panel	Sandwich Panel / Corrugated Steel Sheet
Window	Aluminium Alloy Window / PVC Window / Sandwich Panel Window
Door	Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Rainspout	PVC
Live load on Roof	120kg/Sqm (Color steel panel surrounded)
Wind Resistance Grade	12 Grades
Earthquake-resistance	8 Grades
Structure Usage	Up to 50 years
Temperature Range	-50°C to +50°C
Certification	CE, SGS, ISO9001:2008, ISO14001:2004
Finishing Options	Vast array of colors and textures available
Paint Options	Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized

Structural Steel Fabrication Quality Control

100% testing dimension tolerance <1mm
20% sample welding line ultrasonic testing, no fault, full penetration
20% magnetic powder testing, no bubble, no defect, Smooth and Full
Supply third-party inspection assistance

Installation Process

We provide detailed construction drawings prior to installation for each project. Our team can dispatch engineers to guide on-site installation or handle the complete installation process with our professional construction team.
