Prefab Steel Structure Warehouse with Glass Wool Sandwich Panels

Large Image : Prefab Steel Structure Warehouse with Glass Wool Sandwich Panels

Product Details:

Place of Origin:	China
Brand Name:	Ruly Steel
Certification:	SGS, BV, ISO
Model Number:	Ruly0399

Payment & Shipping Terms:

Minimum Order Quantity:	500 Square Meter
Price:	USD29-USD99 Per Square Meter
Packaging Details:	As request
Delivery Time:	30 Days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	20000 Square Meter Per Month

Contact Now

Prefab Steel Structure Warehouse with Glass Wool Sandwich Panels

Description

Features:	Steel Structure Warehouse	Application:	Steel Structure Factory Warehouse Building Prefab Structural Steel Frame Buildings
Type:	Prefab Steel Buildings	Wall And Roof:	Glass Wool Sandwich Panel
Raw Steel Material:	Q235B, Q355B, ASTM A36	Surface Treatment:	Painting
Working Scope:	Design,Fabrication, Installation	Service Life:	50 Years
Highlight:	Q355B Steel Structure Food Warehouse , Prefabricated Steel Structure Food Warehouse , SGS Prefabricated Steel Structure Installation

Steel Structure Food Warehouse Prefabricated Steel Structure Installation

Product Specifications

Attribute	Value
Application	Steel Structure Factory Warehouse Building Prefab Structural Steel Frame Buildings
Features	Steel Structure Warehouse
Type	Prefab Steel Buildings
Wall and Roof	Glass wool sandwich panel
Raw steel material	Q235B, Q355B, ASTM A36
Surface treatment	Painting
Working scope	Design, Fabrication, Installation
Service life	50 Years

Key Features

Attractive design with beautiful and elegant appearance using color steel sandwich panels
Lightweight construction for convenient shipping and handling
Easy assembly and dismantling with simple tools (plugs and screws)
Sturdy steel frame structure with sandwich panels for durability
Completely waterproof construction
Customizable roof, wall, doors, and windows to meet specific requirements
Long-lasting anti-corrosion coating on steel frame parts for 50+ years of service

Technical Specifications

Main Structure - Column	Q355/Q235 H-steel, Box column available
Main Structure - Rafter, Beam	Q355/Q235 H-steel
Surface Processing Options	1. Epoxy zinc-rich primer + epoxy mica intermediate paint (120 μm thickness) 2. Hot dip galvanization
Sub Structure - Purlin	Q355B, C/Z steel section, galvanization 275g/m²
Sub Structure - Angle brace	Q235B, L-steel
Sub Structure - Cross bracing	Q235B round bar, L-steel
Sub Structure - Tie bar	Q235B, round pipe
Sub Structure - Batter brace	Q235B, round bar
Roof System - Panel Options	1. Insulated sandwich panel (PU, rock wool, glass fiber, EPS) with steel sheets (50mm/75mm/100mm thickness) 2. Steel plate (0.4mm/0.5mm thickness)
Roof System - Gutter Options	1. Galvanized steel gutter (2.0mm/2.5mm/3.0mm thickness) 2. Painted, pre-finished steel gutter (0.4mm/0.5mm/0.6mm thickness)
Wall System - Panel Options	1. Insulated sandwich panel (PU, rock wool, glass fiber, EPS) with steel sheets (50mm/75mm/100mm thickness) 2. Steel plate (0.4mm/0.5mm thickness) 3. Brick wall (provided by client)
Door Options	1. Roller door for truck (custom size) 2. Sliding door for truck (custom size) 3. Access door (steel door, glass door etc.)
Window Options	PVC or Aluminum frame (fixed, swing, sliding, louver etc.), custom sizes available
Accessories and Fasteners	Anchor bolts, chemical bolts, high strength bolts, ordinary bolts, self-drilling screws, rivets etc.
Other Options	Crane systems available (5T, 6T, 10T, 16T, 30T etc.)

Component Production

Frequently Asked Questions

What is the derust grade for the steel structure?

For the main steel structure, the derust grade is ball blasting Sa 2.5, and manual derust St2.0 on secondary steel structure.

How is the installation process handled?

We provide detailed construction drawings as a manual to guide you through the building erection and installation process step by step.

What are the common types of industrial buildings?

Portal frame is widely used for industrial workshops, office buildings, shopping malls and warehouses. Other types can be designed and manufactured according to customer requirements.

What maintenance is required?

Painting touch-ups should be done after frame installation to ensure the surface remains protected for extended periods.
