Prefab Steel Structure Basketball Court Multi-Court Large Span

Prefab Steel Structure Basketball Court Multi-Court Large Span
Prefab Steel Structure Basketball Court Multi-Court Large Span
Prefab Steel Structure Basketball Court Multi-Court Large Span Prefab Steel Structure Basketball Court Multi-Court Large Span Prefab Steel Structure Basketball Court Multi-Court Large Span Prefab Steel Structure Basketball Court Multi-Court Large Span Prefab Steel Structure Basketball Court Multi-Court Large Span Prefab Steel Structure Basketball Court Multi-Court Large Span

Large Image :  Prefab Steel Structure Basketball Court Multi-Court Large Span

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: CE,AISC,SGS, BV, ISO,GB
Model Number: RULYY004
Payment & Shipping Terms:
Minimum Order Quantity: 200 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Structure Basketball Court Multi-Court Large Span

Description
Features: Multi-court Combination Application: Prefab Steel Structure Basketball Court
Type: Portal Frame Raw Steel Material: Q235B, Q355B
Surface Treatment: Painting Galvanized Service Life: 50 Years
Wall And Roof: Steel Cladding Sheet,Sandwich Panel Working Scope: Design,Fabrication, Installation
Highlight:

Prefab Steel Structure Basketball Court

,

Q355B Steel Structure Basketball Court

,

Galvanized Prefab Steel Frame Buildings

Large Span Multi Court Prefab Steel Structure Basketball Court Large Indoor Area
Product Specifications
Attribute Value
Application Prefab Steel Structure Basketball Court
Features Multi-court Combination
Type Portal Frame
Raw steel material Q235B, Q355B
Surface treatment Painting Galvanized
Service life 50 Years
Wall and Roof Steel cladding sheet, Sandwich Panel
Working scope Design, Fabrication, Installation
Product Overview
Our Large Span Multi-Court Prefab Steel Structure Basketball Court offers an ideal solution for indoor sports facilities with various color options available. Steel-framed gymnasiums are particularly suitable for regions with extreme weather conditions, providing a weather-resistant environment for sports activities.
Key Advantages
  • Exceptional Durability: Withstands strong winds, extreme weather, and seismic activity better than wood or concrete. Anti-corrosive treatment prevents rust and oxidation.
  • Large Span Capability: Ideal for gymnasium requirements with wide, unobstructed spaces and excellent visibility.
  • Versatile Design: Easily reconfigurable for multiple uses including concerts and events. Allows for future expansion.
  • Cost-Effective: Prefabricated components reduce construction time, labor costs, and equipment rental expenses.
  • Low Maintenance: Minimal upkeep required with easy repair or replacement of damaged components.
Prefab Steel Structure Basketball Court Multi-Court Large Span 0
Technical Specifications
Name Easy Assemble Multi-Colored Prefab Steel Structure Poultry Shed Large Span Environmental Friendly
Structure Type Gable frame, single ridge, clean span or two spans
Length Scope 50-150m
Width Scope 35-100m
Eave Height Scope 2.5-10m
Roof Slope 10%
Gable Wall Column Spacing 7.5m
Roof Sandwich panel or single layer steel cladding sheet
Wall Sandwich panel or single layer steel cladding sheet
Door Sliding door, roller door, lifting door, Mandoor
Window Fixed window, sliding window
Ventilator Unpower ventilator, electric ventilator, Fans
Material Specifications
Component Specification
Steel Frame H section steel | Q235/Q355 steel 8mm/10mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20,Grade 10.9
Supporting System Angle brace | L50x4,Steel Q235, processed and painted
Horizontal brace Φ20, Steel Q235, processed and painted
Column brace Φ20, Steel Q235, processed and painted
Tie rod Φ89*3, Steel Q235, processed and painted
Ordinary bolt M12 Galvanized bolt
Our Manufacturing Facility
Our steel structure fabrication factory covers 35,000㎡ with 20,000㎡ of workshop space. We operate three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines, and various profiling steel sheet machines equipped with advanced technology including plasma cutting machines.
Prefab Steel Structure Basketball Court Multi-Court Large Span 1
Our Services
  • Structural steel fabrication, painting, galvanizing, pre-assembly
  • Designing, fabrication and installation for prefabricated steel structure buildings
  • Development of fabrication drawings based on your architectural plans
  • Engineering consulting services
Prefab Steel Structure Basketball Court Multi-Court Large Span 2
Quality Control
  • 100% dimensional tolerance testing (<1mm)
  • 20% sample welding line ultrasonic testing (full penetration, no faults)
  • 20% magnetic powder testing (no bubbles or defects)
  • Third-party inspection assistance available
Prefab Steel Structure Basketball Court Multi-Court Large Span 3
Packing and Transportation
All structural components, panels, bolts, and accessories are packed to withstand ocean transportation and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts at our factory loading site to ensure damage-free transportation.
Prefab Steel Structure Basketball Court Multi-Court Large Span 4
