Light Steel Structure Warehouse Building Q235B Q355B Material

Light Steel Structure Warehouse Building Q235B Q355B Material
Light Steel Structure Warehouse Building Q235B Q355B Material
Light Steel Structure Warehouse Building Q235B Q355B Material Light Steel Structure Warehouse Building Q235B Q355B Material Light Steel Structure Warehouse Building Q235B Q355B Material Light Steel Structure Warehouse Building Q235B Q355B Material Light Steel Structure Warehouse Building Q235B Q355B Material Light Steel Structure Warehouse Building Q235B Q355B Material Light Steel Structure Warehouse Building Q235B Q355B Material

Large Image :  Light Steel Structure Warehouse Building Q235B Q355B Material

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0325
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Light Steel Structure Warehouse Building Q235B Q355B Material

Description
Application: Light Steel Warehouse Type: Steel Structure Warehouse
Raw Steel Material: Q235B, Q355B Working Scope: Design,Fabrication, Installation
Surface Treatment: Painting Service Life: 50 Years
Highlight:

Agricultural Lightweight Steel Warehouse

,

Q235B Lightweight Steel Warehouse

,

Agricultural Steel Structure Building

Agricultural Products Lightweight Steel Warehouse Steel Structure Building
Product Specifications
Attribute Value
Application Light Steel Warehouse
Type Steel Structure Warehouse
Raw steel material Q235B, Q355B
Working scope Design, Fabrication, Installation
Surface treatment Painting
Service life 50 Years
Product Overview

Steel structure warehouses and factory buildings are among the most common structural forms in modern construction engineering. These structures are widely used in large-scale industrial facilities, agricultural storage, and commercial buildings due to their lightweight nature and simplified construction process.

Structural Details
Feature Specification
Structure Type Gable frame, single ridge, clean span or two spans
Length 40-100m
Width 20-80m
Eave Height 6-15m
Roof Slope 10%
Gable Wall Column Spacing 7.5m
Roof Glass wool sandwich panel
Wall Glass wool sandwich panel
Door Sliding door
Window Ribbon Skylight
Height difference between indoor and outdoor 300mm
Material Specifications
Component Specification Material Treatment
Column H-section steel Q235B,Q345B Paint or Hot dip galvanized
Beam H-section steel Q235B,Q345B Paint or Hot dip galvanized
Bracing Steel rod, Steel pipe, Angle steel Q235B,Q345B -
Purlin C or Z shape, thickness: 1.8mm~3.0mm Q235B,Q346B Hot dip galvanized
Wall and roof panel EPS, Rock wool, Pu, Glass wool Sandwich panel or Single sheet Steel T=0.426~0.8mm, insulation T=50~150mm Alu-zinc 150g, Fluorocarbon paint
Door Sliding or rolling door Steel or Aluminum sheet, T=1.0~1.5mm Paint or Hot dip galvanized
Window Alloy-Glass, Aluminium alloy-shutter T=1.0~2.0mm Alloy
Lighting panel FRP, T=1.5mm or T=1.8mm Coefficient of thermal expansion: 2.2x10-5/cm/cm/℃ Light transmittance 85%
Ventilator Turbine ventilator, and electric type Steel, stainless steel, PC Paint or Hot dip galvanized, 304
Gutter Galvanized or stainless steel plate T=2.0mm Hot dip galvanized, 304
Downpipe PVC pipe, Color steel pipe T=0.5mm Φ110, 160, 200 Paint
Bolt Ordinary, high strength 10.9S, 4.8s Hot dip galvanized
Anchor bolt Steel rod M24, M27, M30 Q235B -
Light Steel Structure Warehouse Building Q235B Q355B Material 0
Our Services
  • Structural steel fabrication, painting, galvanizing, pre-assembly
  • Designing, fabrication and installation for prefabricated steel structure buildings
  • Deepening or designing fabrication drawings based on your architectural plans
  • Engineering consulting services
Light Steel Structure Warehouse Building Q235B Q355B Material 1 Light Steel Structure Warehouse Building Q235B Q355B Material 2
Frequently Asked Questions
1. Are you a manufacturer or trading company?

We are a manufacturer. We welcome visits to our facility where our quality control process and sales team can demonstrate our professionalism. Visiting also ensures you receive the most competitive pricing.

2. Is your pricing competitive?

Our business objective is to provide the best price for equivalent quality and the best quality for equivalent price. We strive to reduce your costs while guaranteeing product quality.

3. Can you provide installation support?

We provide detailed installation drawings for each project. We can send engineers to guide installation or provide a complete construction team for direct installation.

4. Do you offer design services?

Yes, we provide complete design solutions using AutoCAD, PKPM, MTS, 3D3S, Tarch, and Tekla Structures. We can create proposal drawings, shop drawings, 3D models, and installation drawings.

5. What is the delivery time?

Delivery time depends on order quantity. Typically, delivery to the nearest Chinese seaport takes 40 days after receiving deposit.

6. How are products packed and transported?

All structural components, panels, bolts, and accessories are packed in standard ocean-transport suitable packaging and loaded into 40'HQ containers.
