Galvanized Steel Structure Warehouse Building with H-Section Frame

Large Image : Galvanized Steel Structure Warehouse Building with H-Section Frame

Product Details:

Place of Origin:	Qingdao,China
Brand Name:	Ruly Steel
Certification:	CE,AISC,SGS, BV, ISO,GB
Model Number:	RulyX026

Payment & Shipping Terms:

Minimum Order Quantity:	200 square meters
Price:	USD25-USD45 Per Square Meter
Packaging Details:	40HQ/Open top container
Delivery Time:	20 days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	20,000 square meters or 1,500 tons per month

Contact Now

Galvanized Steel Structure Warehouse Building with H-Section Frame

Description

Raw Steel Material:	Q235B, Q355B, ASTM A36	Application:	Steel Workshop, Steel Structure Platform, Structural Roofing, Frame Part
Columns & Beams:	H-Section Steel	Installation:	Engineer Guidance On Site
Drawing:	CAD, TEKLA, 3D Model, PKPM, BIM	HS Code:	9406900090
Transport Package:	Standard Export Package Or Customer′s Requirement	Production Capacity:	30000ton/Year
Highlight:	Strong Industrial Steel Structure Warehouse , Metal Galvanized Portal Frame Warehouse , Industrial Steel Structure Warehouse

Strong Industrial Steel Structure Warehouse Building Metal Galvanized Portal Frame

Product Specifications

Attribute	Value
Raw Steel Material	Q235B, Q355B, ASTM A36
Application	Steel Workshop, Steel Structure Platform, Structural Roofing, Frame Part
Columns & Beams	H-Section Steel
Installation	Engineer Guidance on Site
Drawing	CAD, TEKLA, 3D Model, PKPM, BIM
HS Code	9406900090
Transport Package	Standard Export Package or Customer′s Requirement
Production Capacity	30000ton/Year

Product Overview

Steel structure buildings combine traditional construction techniques with modern industrial production methods, achieving fast, efficient, and environmentally friendly construction through factory prefabrication and on-site assembly.

The steel frame structure adopts high-quality high-strength steel that has been precisely manufactured to ensure structural integrity, safety, and excellent seismic resistance. Components are prefabricated in a factory environment and then modularly assembled on site, which improves construction productivity, greatly shortens construction time, and minimizes costs.

Material Specifications

Main Steel Frame - Column	Q235, Q355 Welded H Section Steel
Main Steel Frame - Beam	Q235, Q355 Welded H Section Steel
Secondary Frame - Purlin	Q235 C and Z purlin
Knee Bracing	Q235 Angle Steel
Tie Bar	Q235 Circular Steel Pipe
Bracing	Q235 Round Bar
Column and Horizontal Bracing	Q235 Angle Steel, Round Bar or Steel Pipe
Roof Panel	EPS Sandwich Panel / Fiber Glass Sandwich Panel / Rock Wool Sandwich Panel / PU Sandwich Panel / Steel Sheet
Wall Panel	Sandwich Panel / Corrugated Steel Sheet
Structure Usage	Up to 50 years

Service Advantages

Professional Design: Senior design team provides customized drawings and steel usage calculations
Exquisite Craftsmanship: Skilled production team with advanced equipment ensures excellent quality
One-Stop Service: Comprehensive solutions from design to installation
Strict Quality Control: International standards compliance for products and services
High-Quality After-Sales: Quick response and comprehensive maintenance services

Packing and Delivery

Standard Sea Freight Packaging: Reinforced packaging for structural components, panels, and accessories
40' HQ Container Loading: Optimized space utilization for safe transportation
Professional Loading Team: Skilled workers using cranes and forklifts following strict procedures

Project Case: Marriott AC Hotel Guyana & Retail Building

Project Usage	Marriott AC Hotel Guyana & Retail Building
Building Structure Type	3 & 6 Floor Steel Buildings
Steel Structure Weight	860 Ton
Raw Steel Material	ASTM A572 G50
Welding Technique	AWS-D1.1
Maximum Thickness Of Steel Plate	65mm
Our Work Scope	Design 3D Tekla Model, Fabrication Drawings, Installation Drawings; Fabrication Steel Structure & Loading
Project Location	Guyana
Date	January, 2023 - March, 2023

Quality Control

Raw Material Quality Control: Thickness tolerance <0.25mm, yield and tension strength testing, third-party inspection certificates

Structural Steel Fabrication Quality Control: 100% dimension testing (<1mm tolerance), 20% ultrasonic welding tests, magnetic powder testing

Surface Treatment: Shot blasting grade Sa. 2.5, paint primer within 5 hours, dry film thickness >75UM
