Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized

Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized
Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized
Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized

Large Image :  Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, ,ISO, BV
Model Number: Ruly0028
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized

Description
Name: Prefabricated Steel Frame Buildings Application: Large Space Steel Buildings
Usage: Steel Structure Workshop, Metal Warehouse, Factory Buildings Raw Steel Material: Q235B, Q355B
Surface Treatment: Painting Or Hot-dip Galvanize Service Life: 50 Years
Wall And Roof: Steel Cladding/Rock Wool/Glass Wool/EPS/PU Sandwich Panel Columns And Beam: H Section Column&Beam
Highlight:

Customized Prefabricated Steel Frame Buildings

,

Galvanized Prefabricated Steel Frame Buildings

,

Customized galvanized steel frame

Customized Prefabricated Steel Frame Buildings Hot Dip Galvanized
Product Specifications
Attribute Value
Name Prefabricated Steel Frame Buildings
Application Large Space Steel Buildings
Usage Steel Structure Workshop, Metal Warehouse, Factory Buildings
Raw steel material Q235B, Q355B
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof Steel cladding/Rock wool/Glass wool/EPS/PU sandwich panel
Columns and Beam H Section Column & Beam
Key Advantages
  • Lower cost compared to concrete structures with high repurchase rate
  • Prefabricated design enables quick assembly with bolts and fast construction
  • Durable structure with excellent ductility, designed for anti-seismic and wind-resistant properties
Detailed Specifications
No. Item Details
1 Material Carbon structural steel
2 Production Lead Time Normally 45 days after down payment (varies by quantity)
3 Quality Certification Factory quality certificate, third-party available upon request
4-7 Dimensions H beam: 4000-15000mm length
Web plate: 6-32mm thickness
Wing plate: 6-40mm thickness
200-1200mm height
8 Color Customizable to customer requirements
9 Size Minimum order quantity: 1000 m² (width × length × eave height)
10-24 Components Base: Cement and steel foundation bolts
Main Frame: H Steel beam, Q235/Q345 steel H beam and columns (painted or galvanized)
Secondary Frame: Galvanized C/Z purlin, steel bracing, tie bar, knee brace, flashing
Materials: Q235B, Q345B or other standards (ASTM, BSEN, DIN, IPE, AISI, JIS)
Purlin: C120-C320 or Z100-Z20
Column: X-type, tree type, lattice, Cross, Box etc.
Bolt: Plain bolt and High-strength bolt
Roof & Wall: PU sandwich panel, Rockwool sandwich panel or Corrugated steel sheet
Surface: Two layers of rust-proof painting or Hot Dip Galvanized
Sheet: 0.5mm or 0.6mm galvanized sheet
Finishing: Various colors/textures, alkyd painting, epoxy zinc, or galvanized
25-30 Applications Steel workshops, warehouses, and plants
Steel web frame structures
Portal frame products
High-rise building projects
Other steel structure buildings
Our Service Scope
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Design, fabrication, and installation of prefabricated steel structures
  • Detailed fabrication drawings based on your architectural plans
  • Engineering consulting services
Custom Prefabricated Steel Frame Buildings Hot Dip Galvanized 0
Why Choose Our Steel Structures?
  • Cost-Effective: Professional design reduces construction time and material costs
  • Eco-Friendly: Specialized cladding provides excellent insulation; materials are recyclable
  • Durable & Aesthetic: Spacious designs with elegant profiles and long service life
  • Quality Assurance: "Quality first, Customer first" principle with factory certifications
Project Requirements Form
1. Location (where will be built?) _____country, area
2. Size: length×width×height _____mm×_____mm×_____mm
3. Wind load (max. wind speed) _____kn/m², _____km/h, _____m/s
4. Snow load (max. snow height) _____kn/m², _____mm
5. Anti-earthquake _____level
6. Brickwall needed or not If yes, 1.2m high or 1.5m high
7. Thermal insulation EPS, fiberglass wool, rockwool, PU sandwich panels or metal steel sheets
8. Door quantity & size _____units, _____(width)mm×_____(height)mm
9. Window quantity & size _____units, _____(width)mm×_____(height)mm
10. Crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
