50-Year Painting Prefabricated Steel Frame Buildings for Agriculture

50-Year Painting Prefabricated Steel Frame Buildings for Agriculture
50-Year Painting Prefabricated Steel Frame Buildings for Agriculture
50-Year Painting Prefabricated Steel Frame Buildings for Agriculture 50-Year Painting Prefabricated Steel Frame Buildings for Agriculture 50-Year Painting Prefabricated Steel Frame Buildings for Agriculture 50-Year Painting Prefabricated Steel Frame Buildings for Agriculture 50-Year Painting Prefabricated Steel Frame Buildings for Agriculture 50-Year Painting Prefabricated Steel Frame Buildings for Agriculture 50-Year Painting Prefabricated Steel Frame Buildings for Agriculture

Large Image :  50-Year Painting Prefabricated Steel Frame Buildings for Agriculture

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, ,ISO, BV
Model Number: Ruly0035
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

50-Year Painting Prefabricated Steel Frame Buildings for Agriculture

Description
Application: Large Steel Frame Structure Metal Buildings Usage: Farmers Produce Market Buildings, Steel Agricultural Buildings
Type: Prefabricated Steel Frame Buildings Surface Treatment: Painting Or Hot-dip Galvanize
Service Life: 50 Years Wall And Roof: Steel Cladding/Rock Wool/Glass Wool/EPS/PU Sandwich Panel
Columns And Beam: H Section Column&Beam Drawing: Design The Drawing As Your Demand
Highlight:

Painting Prefabricated Steel Frame Buildings

,

50 Years Prefabricated Steel Frame Buildings

,

50 Years steel frame house construction

Painting Prefabricated Steel Frame Buildings With 50 Years Life
Product Specifications
Attribute Value
Application Large Steel Frame Structure Metal Buildings
Usage Farmers Produce Market Buildings, Steel Agricultural Buildings
Type Prefabricated Steel Frame Buildings
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof Steel cladding/Rock wool/Glass wool/EPS/PU sandwich panel
Columns and Beam H Section Column & Beam
Drawing Design The Drawing as Your Demand
Project Advantages
  • Cost savings: Prefabricated Steel Frame Buildings are inexpensive to manufacture and erect, requiring less maintenance than traditional building methods.
  • Creativity: Steel allows for long column-free spans and can accommodate natural light in any shape of structure.
  • Control and Management: Steel structures are fabricated at factory and rapidly erected at construction site by skilled personnel, ensuring safe construction process.
Material Specifications
Component Specification
Steel Frame H section steel | Q235/Q345 steel 8mm/10mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20, Grade 10.9
Supporting System Angle brace: L50x4, Steel Q235, processed and painted
Horizontal brace: Φ20, Steel Q235, processed and painted
Column brace: Φ20, Steel Q235, processed and painted
Tie rod: Φ89*3, Steel Q235, processed and painted
Ordinary bolt M12 Galvanized bolt
Roof Purlin: C160*60*2.5, Steel Q235, galvanized and painted
Roof panel: Sandwich panel or corrugated steel sheet
Sky light: 6mm thick PVC
Walls Purlin: C160*60*2.5, Steel Q235, painted
Wall: Sandwich panel or corrugated steel plate
Ventilation Ventilation ball
Doors & windows Rolling door/sliding door PVC/alu/steel/window
Our Production Capabilities
Our steel structure fabrication factory covers 35,000㎡ with 20,000㎡ workshop area. We operate three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines and various types of profiling steel sheet machines with advanced equipment including plasma cutting machines.
50-Year Painting Prefabricated Steel Frame Buildings for Agriculture 0
Why Choose Us?
  • Professional design team to create custom drawings or calculate steel quantities
  • Skilled fabrication team with advanced equipment and project-specific production schedules
  • One-stop service with integrated project proposals
  • Quality control team ensuring products meet specifications
  • Comprehensive after-sales service including maintenance support
Project Information Required for Quotation
Item Details Needed
1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 Snow load (max. snow height) _____kn/m2, _____mm
5 Anti-earthquake _____level
6 Brickwall needed or not (If yes, 1.2m high or 1.5m high)
7 Thermal insulation (EPS, fiberglass wool, rockwool, PU sandwich panels or metal steel sheets)
8 Door quantity & size _____units, _____(width)mm*_____(height)mm
9 Window quantity & size _____units, _____(width)mm*_____(height)mm
10 Crane needed or not (If yes, _____units, max. lifting weight____tons; max. lifting height _____m)
