Superior Metal Buildings Hangar Prefab Durable Industrial Construction Building
Product Attributes
| Attribute |
Value |
| Raw Steel Material |
Q235B, Q355B, ASTM A36 |
| Application |
Steel Workshop, Steel Structure Platform, Structural Roofing, Frame Part |
| Surface Treatment |
Painting or Hot-DIP Galvanized |
| Service Life |
50 Years |
| Wall and Roof |
Steel cladding sheet, Sandwich Panel |
| Columns & Beams |
H-Section Steel |
| Shot Blasting Level |
SA 2.5 |
| Certification |
CE, AISC, SGS, BV, ISO, GB |
| Installation |
Engineer Guidance on Site |
| Drawing |
CAD, TEKLA, 3D Model, PKPM, BIM |
| HS Code |
9406900090 |
| Transport Package |
Standard Export Package or Customer′s Requirement |
| Production Capacity |
30000ton/Year |
| Features |
Prefab Steel Structure, Large Span, Multi-Floor |
| Connection Form |
Bolt Connection |
| Parapet Wall |
As Requested |
Product Description
Our steel structure buildings offer high fire resistance and strong corrosion protection. The primary load-bearing components consist of steel columns, beams, and roof trusses, connected through welding, bolting, or riveting.
Roof and wall options include composite panels or veneer. Galvanized sheet metal prevents rust and corrosion, while self-tapping screws ensure tight connections to prevent leakage. Composite panels with PU, EPS, fiberglass, or rock wool cores provide excellent thermal insulation and fire resistance. Brick walls are also available for structural maintenance.
Material Specifications
| Component |
Specification |
| Main Steel Frame (Column) |
Q235, Q355 Welded H Section Steel |
| Main Steel Frame (Beam) |
Q235, Q355 Welded H Section Steel |
| Secondary Frame (Purlin) |
Q235 C and Z purlin |
| Knee Bracing |
Q235 Angle Steel |
| Tie Bar |
Q235 Circular Steel Pipe |
| Bracing |
Q235 Round Bar |
| Column and Horizontal Bracing |
Q235 Angle Steel, Round Bar or Steel Pipe |
| Roof Panel |
EPS Sandwich Panel / Fiber Glass Sandwich Panel / Rock Wool Sandwich Panel / PU Sandwich Panel / Steel Sheet |
| Wall Panel |
Sandwich Panel / Corrugated Steel Sheet |
| Window |
Aluminium Alloy Window / PVC Window |
| Door |
Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door |
| Downspout |
PVC |
| Structure Usage |
Up to 50 years |
| Finishing Options |
Vast array of colors and textures available |
| Paint Options |
Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized |
Project Showcase
High-End Intelligent Hydraulic Machine Tool Equipment
Size: Total Area 9,702 Sqm
Steel Structure Weight: 630Ton
Logistics Steel Warehouse For High-Speed Rail Station
Size: Total Area 24,570 Sqm
Steel Structure Weight: 985Ton
Textile Manufacturing Machine Equipment
Size: Total Area 6,615 Sqm
Steel Structure Weight: 750Ton
About Our Company
Qingdao Ruly Steel Engineering Co., Ltd is a professional steel structure fabrication and engineering company based in Qingdao, China. We specialize in integrated steel structure design, R&D, manufacturing, and installation for various projects including prefabricated steel workshops, warehouses, logistics parks, high-rise buildings, exhibition centers, stadiums, and industrial facilities.
Our 35,000 square meter facility includes a 20,000 square meter processing plant with over 100 employees and monthly production capacity exceeding 1,500 tons. We manufacture light/heavy H steel, BOX steel, cross-shaped section steel, large diameter submerged arc straight-weld pipes, and various structural components.
We maintain ISO 9001, ISO 14001, and GB/T 28001 certifications, along with ASTM and SGS certifications, ensuring international quality standards for all our products and services.
Certifications
Our Services
- Structural steel fabrication, painting, galvanizing, and pre-assembly
- Design, fabrication, and installation of prefabricated steel structures
- Detailed fabrication drawings based on your architectural plans
- Technical advice for usage, maintenance, and improvements
Quality Control
Raw Material Quality Control
- Thickness tolerance <0.25mm
- Yield and tension strength testing in-house
- Third party inspection certificate
- Supply traceable mill certificate
Structural Steel Fabrication Quality Control
- 100% testing dimension tolerance <1mm
- 20% sample welding line ultrasonic testing
- 20% magnetic powder testing
- Third-party inspection assistance
Surface Treatment Quality Control
- Shot blasting grade Sa. 2.5
- Paint primer within 5 hours after shot blasting
- Holiday-free coatings
- Dry Film Thickness (DFT) >75UM
Frequently Asked Questions
Q: Are you a manufacturer or trading company?
A: We are a manufacturer with our own factory. You're welcome to visit our facility to inspect our production processes and quality control measures.
Q: How competitive are your prices?
A: We strive to offer the best value - either the best price for equivalent quality or superior quality at comparable prices. We continuously work to optimize costs without compromising quality.
Q: Do you provide installation services?
A: We provide detailed installation drawings at no cost. We can send engineers as installation supervisors or complete installation teams upon request.
Q: Can we inspect during production and loading?
A: Yes, you're welcome to send inspectors at any stage of production, including during container loading.
Q: Do you offer design services?
A: Yes, we provide complete design solutions using AutoCAD, PKPM, MTS, 3D3S, Tarch, and Tekla Structures for various industrial and commercial buildings.
Q: What is your typical delivery time?
A: Delivery typically takes 40 days after deposit receipt to the nearest Chinese seaport, depending on order quantity.
Q: How can I request a quotation?
A: Contact us via email, phone, WhatsApp, or Viber anytime. We guarantee responses within 8 hours.
Packing and Transportation
All structural components, panels, bolts, and accessories are packed in standard export packages suitable for ocean transportation, typically loaded into 40'HQ containers. Our skilled workers use cranes and forklifts at our factory loading site to ensure safe handling and prevent damage during loading.
Design Capabilities
For each project, we provide preliminary layout drawings, 3D Tekla models, and detailed installation drawings to ensure project success.
Why Choose Us?
- Professional design team capable of custom solutions or quantity calculations
- Skilled fabrication team with advanced equipment and project-specific schedules
- Comprehensive one-stop service with integrated project proposals
- Dedicated QC team ensuring product and service compliance
- Responsive after-sales support for maintenance and technical questions
Our Production Line
