Prefab Steel Building Workshop Warehouse Q235B Q355B ASTM A36

Large Image : Prefab Steel Building Workshop Warehouse Q235B Q355B ASTM A36

Product Details:

Place of Origin:	Qingdao,China
Brand Name:	Ruly Steel
Certification:	CE,AISC,SGS, BV, ISO,GB
Model Number:	RulyX052

Payment & Shipping Terms:

Minimum Order Quantity:	200 square meters
Price:	USD25-USD45 Per Square Meter
Packaging Details:	40HQ/Open top container
Delivery Time:	20 days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	20,000 square meters or 1,500 tons per month

Contact Now

Prefab Steel Building Workshop Warehouse Q235B Q355B ASTM A36

Description

Features:	Prefab Steel Structure, Large Span, Multi-Floor	Raw Steel Material:	Q235B, Q355B, ASTM A36
Application:	Steel Workshop, Steel Structure Platform, Structural Roofing, Frame Part	Surface Treatment:	Painting Or Hot-DIP Galvanized
Service Life:	50 Years	Wall And Roof:	Steel Cladding Sheet,Sandwich Panel
Columns & Beams:	H-Section Steel	Shot Blasting Level:	SA 2.5
Certification:	CE, AISC, SGS, BV, ISO, GB	Installation:	Engineer Guidance On Site
Drawing:	CAD, TEKLA, 3D Model, PKPM, BIM	HS Code:	9406900090
Transport Package:	Standard Export Package Or Customer′s Requirement	Production Capacity:	30000ton/Year
Connection Form:	Bolt Connection	Parapet Wall:	As Requested
Highlight:	Prefab Fireproof Metallic Structure Warehouse , Fireproof Metallic Structure Warehouse , Prefabricated Steel Building Warehouse

Steel Sheds Prefabricated Steel Building

Prefabricated fireproof metallic structure warehouse with high durability and corrosion resistance.

Product Attributes

Raw Steel Material	Q235B, Q355B, ASTM A36
Application	Steel Workshop, Steel Structure Platform, Structural Roofing, Frame Part
Surface Treatment	Painting or Hot-DIP Galvanized
Service Life	50 Years
Wall and Roof	Steel cladding sheet, Sandwich Panel
Columns & Beams	H-Section Steel
Shot Blasting Level	SA 2.5
Certification	CE, AISC, SGS, BV, ISO, GB
Installation	Engineer Guidance on Site
Drawing	CAD, TEKLA, 3D Model, PKPM, BIM
HS Code	9406900090
Transport Package	Standard Export Package or Customer's Requirement
Production Capacity	30000ton/Year
Features	Prefab Steel Structure, Large Span, Multi-Floor
Connection Form	Bolt Connection
Parapet Wall	As Requested

Product Description

Our steel structure buildings feature high fire resistance and strong corrosion resistance. The main bearing components are composed of steel, including steel columns, steel beams, and steel roof trusses, connected by welds, bolts, or rivets.

The roof and wall can be made of composite panel or veneer. Galvanized sheet metal prevents rust and corrosion, while self-tapping screws ensure tight connections between plates to prevent leakage. Composite panels with PU, EPS, fiber glass, or rock wool insulation provide excellent thermal and fire-retardant properties. Brick walls can also be used for steel structure maintenance.

Material Specifications

Component	Specification
Main Steel Frame (Column)	Q235, Q355 Welded H Section Steel
Main Steel Frame (Beam)	Q235, Q355 Welded H Section Steel
Secondary Frame (Purlin)	Q235 C and Z purlin
Knee Bracing	Q235 Angle Steel
Tie Bar	Q235 Circular Steel Pipe
Bracing	Q235 Round Bar
Column and Horizontal Bracing	Q235 Angle Steel, Round Bar or Steel Pipe
Roof Panel	EPS Sandwich Panel / Fiber Glass Sandwich Panel / Rock Wool Sandwich Panel / PU Sandwich Panel / Steel Sheet
Wall Panel	Sandwich Panel / Corrugated Steel Sheet
Window	Aluminium Alloy Window / PVC Window
Door	Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Downspout	PVC
Structure Usage	Up to 50 years
Finishing Options	Vast array of colors and textures available
Paint Options	Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized

Project Showcase

Project Usage: High-End Intelligent Hydraulic Machine Tool Equipment

Size of the plant: Total Area 9,702 Sqm

Steel Structure Weight: 630Ton

Project Usage: Logistics Steel Warehouse For High-Speed Rail Station

Size of the plant: Total Area 24,570 Sqm

Steel Structure Weight: 985Ton

Project Usage: Textile Manufacturing Machine Machine Tool Equipment

Size of the plant: Total Area 6,615 Sqm

Steel Structure Weight: 750Ton

Our Company

Qingdao Ruly Steel Engineering Co., Ltd is a professional steel structure fabrication and engineering company located in Qingdao, China. We integrate steel structure design, research and development, manufacturing and installation for various project types including prefabricated steel workshops, warehouses, logistics parks, and other civil building systems.

Our 35,000 square meter facility includes a 20,000 square meter plant with over 100 employees and a monthly production capacity exceeding 1500 tons. We manufacture various steel structure components including light/heavy H steel, BOX steel, and specialized structural elements.

Our company maintains ISO9001:2008 quality management, ISO14001:2004 environmental system, and GB/T28001:2001 occupational health certifications, along with ASTM and SGS product certifications.

Our Services

Structural steel fabrication, painting, galvanizing, and pre-assembly
Designing, fabrication and installation for prefabricated steel structure buildings
Development of fabrication drawings based on your architectural plans
Technical advice for usage, maintenance and improvements

Quality Control

Raw material quality control: Thickness tolerance <0.25mm, yield and tension strength testing, third party inspection
Structural steel fabrication: 100% dimension testing (<1mm tolerance), 20% welding line ultrasonic testing
Shot blasting and painting: SA 2.5 grade, roughness >75um, primer within 5 hours, DFT >75UM
Pre-assembly testing of all connection details

Frequently Asked Questions

Are you a manufacturer or trading company?

We are a manufacturer and welcome visits to our facility to observe our quality control processes and receive competitive pricing.

Is your price competitive?

We offer the best price for equivalent quality and the best quality for equivalent prices, working to reduce costs while guaranteeing product quality.

Can you provide installation support?

We provide detailed installation drawings and can send engineers or a full installation team upon request.

Do you accept inspection during production?

We welcome inspectors at any stage of production, including container loading.

Do you offer design services?

Yes, we provide full solution drawings using AutoCAD, PKPM, Tekla Structures and other professional design software.

What is your delivery time?

Standard delivery to nearest Chinese seaport is 40 days after deposit, depending on order quantity.

How can I get a quotation?

Packing and Transport

All structure components, panels, bolts and accessories are packed in standard export packages suitable for ocean transportation in 40'HQ containers. Our skilled workers use cranes and forklifts to prevent damage during loading.

Design Services

We provide preliminary layout drawings, 3D Tekla models and installation drawings to support project completion.

Why Choose Us?

Professional design team capable of creating custom drawings or calculating steel quantities
Skilled fabrication team with advanced equipment and project-specific production schedules
One-stop service with integrated project proposals based on extensive experience
Dedicated QC team ensuring products meet specifications
Comprehensive after-sales service including maintenance support

Our Production Line
