Customizable Prefab Steel Structure Workshop H-Section Beams

Customizable Prefab Steel Structure Workshop H-Section Beams
Customizable Prefab Steel Structure Workshop H-Section Beams
Customizable Prefab Steel Structure Workshop H-Section Beams Customizable Prefab Steel Structure Workshop H-Section Beams Customizable Prefab Steel Structure Workshop H-Section Beams Customizable Prefab Steel Structure Workshop H-Section Beams Customizable Prefab Steel Structure Workshop H-Section Beams Customizable Prefab Steel Structure Workshop H-Section Beams Customizable Prefab Steel Structure Workshop H-Section Beams

Large Image :  Customizable Prefab Steel Structure Workshop H-Section Beams

Product Details:
Place of Origin: Qingdao China
Brand Name: Ruly
Certification: SGS, ,ISO9001, BV, CE, ASTM
Model Number: RulyS014
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meters
Price: USD29-USD53 Per SQM
Packaging Details: 20GP, 40HC,40OT Shipping container standard package
Delivery Time: 25-30 days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 50000 Square Meter Per Month
Contact Now

Customizable Prefab Steel Structure Workshop H-Section Beams

Description
Features: Prefab Steel Structure, Large Span, Multi-Floor Application: Versatile
Corrosion Resistance: Rust-proof Cost: Affordable
Design: Customizable Durability: Long-lasting
Environmental Impact: Low Fire Resistance: High
Flexibility: Easy To Modify Installation: Efficient
Size: Customizable Strength: High
Weight: Lightweight Drawing: CAD, Tekla, 3D Model, Pkpm, Bim
Usage: Steel Structure Construction Surface Treatment: Painting Or Hot-DIP Galvanized
Transport Package: Standard Export Package Or Customers Requirement Origin: Qingdao China
Connection Form: Bolt Connection Type Of Steel For Building Structure: H-Section Steel
Residential Wall Structure: Wall Support Columns & Beams: H-Section Steel
Raw Steel Material: Q235B, Q355b, ASTM A36 Parapet Wall: As Requested
Certification: CE, Aisc, SGS, BV, ISO, GB Residential Wall Structure Building: Steel Cladding Sheet/Sandwich Panel
Wall And Roof: Steel Cladding Sheet, Sandwich Panel Specification: Prefab Steel Buildings
HS Code: 9406900090
Highlight:

Building Steel Beam Column

,

Prefab Steel Structure Workshop

,

Metal Prefab Steel Structure Workshop

Building Steel Beam Column Metal Prefab Steel Structure Workshop
Product Attributes
Attribute Value
Application Versatile
Corrosion Resistance Rust-proof
Cost Affordable
Design Customizable
Durability Long-lasting
Environmental Impact Low
Fire Resistance High
Flexibility Easy to modify
Installation Efficient
Size Customizable
Strength High
Weight Lightweight
Drawing CAD, Tekla, 3D Model, Pkpm, Bim
Usage Steel Structure Construction
Surface Treatment Painting or Hot-DIP Galvanized
Transport Package Standard Export Package or Customers Requirement
Origin Qingdao China
Connection Form Bolt Connection
Type of Steel For Building Structure H-Section Steel
Residential Wall Structure Wall Support
Columns & Beams H-Section Steel
Raw Steel Material Q235B, Q355b, ASTM A36
Parapet Wall As Requested
Certification CE, Aisc, SGS, BV, ISO, GB
Residential Wall Structure Building Steel Cladding Sheet/Sandwich Panel
Features Prefab Steel Structure, Large Span, Multi-Floor
Wall and Roof Steel Cladding Sheet, Sandwich Panel
Specification Prefab steel buildings
HS Code 9406900090
Product Description
High Quality Low Cost Free Design Prefab Steel Structure Workshop Building Construction Prefabricated Metal Warehouse
General Information
Pre Manufactured Steel Structure Workshop / Long Span Heavy Industrial Steel Buildings. This is a heavy industrial steel structure workshop building for production of container. The eave height is 15m. It also has overhead crane of 20 Ton and 50 Ton capacity in the building.
We are one-stop service contractor for steel structure design, fabrication and construction. Portal frame steel structure building project is our main business such as prefabricated steel warehouse, workshop, sheds, garage, office building.
Heavy-duty steel structure workshops are mostly frame or frame structure, with one or more heavy-duty cranes. One or more layers of steel structure platforms are generally arranged in the factory. Most of the steel structure materials are wide-flange H-beams. Mostly high-strength bolted joints, so the manufacturing process of welded H-beam components and the quality control of high-strength bolt installation are the key to the quality of the plant structure.
Project Information for Prefabricated Steel Structure Workshop Buildings
Name Pre Manufactured Steel Structure Workshop / Long Span Heavy Industrial Steel Buildings
Structure Type Portal frame, single ridges, multi spans
Length 350m
Width 80m
Eave Height 15m
Roof Slope 10%
Gable Wall Column Spacing 7.5m
Roof steel cladding sheet, sandwich panel
Wall steel cladding sheet, sandwich panel
Door Sliding door
Window Ribbon Skylight
Height difference between indoor and outdoor 300mm
Material List and Technical Parameters
No. Item Details of steel structure building or steel frame
1 Material carbon structural steel
2 Produce Lead time: Normally 45days after down payment, also according to quantity.
3 Quality Certification: Quality certificate from factory, the third party by client request.
4 Dimensions Length: H beam: 4000-15000mm
5 Thickness web plate: 6-32mm
6 Thickness wing plate: 6-40mm
7 Height 200-1200mm
8 Color According to customers
9 Size MOQ is 1000 m2, width * length * eave height
10 Main components Base: Cement and steel foundation bolts
11 Main frame H Steel beam, Q235 Q345 steel H beam and columns, painted or galvanized, box steel, galvanized C section or steel pipe
12 Secondary frame galvanized C or Z purlin , steel bracing , tie bar , knee brace ,flashing etc.
13 Material Q235B, Q345B or others as buyers' requests, like: ASTM, BSEN, DIN, IPE,AISI,JIS
14 Purlin C or Z purlin: Size from C120~C320, Z100~Z20
15 Column X-type, tree type ,lattice, Cross, Box etc.
16 Bolt Plain bolt and High-strength bolt
17 Roof & wall PU sandwich panel, Rockwool sandwich panel or Corrugated steel sheet
18 Canopy steel sheet, PU sandwich panel, Rockwool sandwich panel
19 Door Sliding or rolling door
20 Window Aluminium alloy window
21 Surface Two lays of rust-proof painting or Hot Dip Galvanized
22 Sheet 0.5mm or 0.6mm galvanized sheet
23 Accessories Semi-transparent skylight belts, Ventilators,down pipe, Galvanized gutter, Trim, flashing, etc
24 Finishing options Vast array of colors and textures available, Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.). Or Galvanized.
25 Usages 1. Steel workshop, steel warehouse, steel structure plant
26 2. Steel web frame structure
27 3. Steel H-column and steel H-beam
28 4. Portal frame products
29 5. High rise building project
30 6. Others steel structure buildings
Steel Structure Fabrication in Our Factory
The floor space of our steel structure fabrication factory is 35,000㎡, and the workshop area is 20000㎡. We own three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines and various types of profiling steel sheet machines with advanced equipment such as plasma cutting machine.
Customizable Prefab Steel Structure Workshop H-Section Beams 0
How to Install
Customizable Prefab Steel Structure Workshop H-Section Beams 1
Packing and Transport
All the structure components, panels, bolts and sort of accessories will be well packed with standard package suitable ocean transportation and loaded into 40'HQ.
All the products are loaded at the loading site of our factory using crane and forklift by our skilled workers, who will prevent the goods to be damaged.
Customizable Prefab Steel Structure Workshop H-Section Beams 2
How to Quote
The following question we need to know before making the price. Just feel free to fill what you know.
1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 snow load (max. snow height) _____kn/m2, _____mm
5 anti-earthquake _____level
6 brickwall needed or not If yes, 1.2m high or 1.5m high
7 thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, the metal steel sheets will be ok. The cost of the latter will be much lower than that of the former
8 door quantity & size _____units, _____(width)mm*_____(height)mm
9 window quanity & size _____units, _____(width)mm*_____(height)mm
10 crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
