Product Details:
|
| Application: | Modern Industrial Steel Structure Workshop | Type: | Prefabricated Steel Frame Buildings |
|---|---|---|---|
| Usage: | Steel Structure Workshop | Our Service: | Design, Fabrication, Construction |
| Service Life: | 50 Years | Surface Treatment: | Painting Or Hot-dip Galvanize |
| Wall And Roof: | Steel Cladding | Columns And Beam: | H-section Steel |
| High Light: | Q355 Prefab Steel Structure Building,Sandblasting Steel Structure Building,Prefab Steel Structure Aircraft Hangar |
||
With the increase of steel production, many steel structure workshops have been put into use, which can be divided into light steel structure workshops and heavy steel structure workshops. Industrial and civil construction facilities made of steel are called steel structures. Steel structure buildings are easy to move and pollution-free.
The characteristics of the steel structure workshop are as follows: 1. The steel structure building has light weight, high strength and large span. 2. The construction period of steel structure is short, and the investment cost is reduced correspondingly. 3. Steel structure buildings have high fire resistance and corrosion resistance.
| Main steel frame | H-section steel | Q355 steel 8mm to 10mm |
| Welding | Automatic Submerged Arc Welding | |
| Rust removing | Sand blasting | |
| surface processing | Alkyd Paint or galvanized | |
| High strength bolt | Grade 10.9 | |
| Supporting system | Angle brace | L50x4,Steel Q235,Process and painting |
| Cross bracing | dia.20 round bar,Steel Q235, process and painting | |
| Tie bar | dia.89*3 round pipe,Steel Q235 Process and painting | |
| Batter brace | dia.12 round bar,Steel Q235 process and painting | |
| Ordinary bolt | Galvanized bolt | |
| Roof | Purlin | C160*60*2.5,steel Q235,Painting or galvanized |
| Out-roof panel | Sandwich panel or corrugated steel plate | |
| Transparent skylight | 6mm thick PVC | |
| Accessories | Sealant,self-tapping screw, etc. | |
| Edge cover | Made of color steel sheet thickness 0.5mm | |
| Gutter | Made of steel sheet thickness 0.8mm, or PVC | |
| Rinspout | dia.110 PVC | |
| Wall | Purlin | C160*60*2.5,steel Q235,paint |
| Wall panel | Sandwich panel or corrugated steel plate | |
| Accessories | Sealant,self-tapping screw etc | |
| Edge cover | Made of color steel sheet thickness 0.5mm | |
| Ventilator | unpowered axial-flow ventilator or monitor roof | |
| Door & window | Rolling door/sliding door, PVC/alu. alloy window | |
| Crane | With or without crane, ranging from 5 tons to 20 tons |
Steel structure engineering is a structure mainly made of steel. It is mainly composed of steel beams, steel columns, steel trusses and other components made of section steel and steel plates. The connection between each component or component is usually connected by welding seam, bolts or rivets.Because of its light weight and simple construction, it is widely used in large factories, Bridges, stadiums, super high-rise buildings and other fields.
1. The dead weight of steel structure is light
2. The reliability of steel structure is high
3, steel vibration resistance (shock), impact resistance is good
4, steel structure manufacturing of a higher degree of industrialization
5, steel structure can be accurately and quickly assembled
6. Large interior space of steel structure
7, easy to make a sealing structure
